| Prod Model: |
P4 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size Of Unit Board: |
128mm*128mm |
| Resolution Of Unit Board: |
32*32 |
| Density Of Pixel: |
62500DOT/Sqm |
| Best Viewing Distance: |
4m |
| Brightness: |
1800-2200CD/Sqm |
| IP Grade: |
IP20-IP65 |
| Refresh Rate: |
>=300Hz |
| Viewing Angle: |
140° |
| Working Voltage: |
AC220V/110V+-10% |
| Life Span: |
100,000h |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Pixel Pitch: |
4mm |
| Pixel Configuration: |
1R,1G,1B |
| Pixel Density: |
27,777 dots / m² |
| Scanning Mode: |
1/8 Scan |
| System Operating Platform: |
WIN XP |
| Display Type: |
LED Video Display |
| Application: |
Shopping Guide |
| IP Rating: |
IP43 |
| Certification: |
ETL |
Product Description
1). Price: We have the best competitive High Cost-effective of Price/ features.
2), Automatic: From selecting LED chip, led encapsulation, PCB soldering, LED module,
Are operated by Automatic machine, improve showing effect of led screen.
3). Quality: From material to product finished, from design to produce, all steps are controlled
By our workshop, that's the guarantee of the reliability.
4). Service: All the life time 11 years is serviced free,
Warranty is up to 6 years, Service time is 24hours x 7 days,
5), Payment: Accept: T/T, L/C, D/P, D/A, MoneyGram, werstern union, and Cash.
* Products list and application area:
A: Outdoor full color LED display: Equally or compactly make the red, green, blue color in one dot,
Equally distribute at the panel, so make the whole led panel, led module, led display.
B: . Apply for physical sports, advertisement, bank, stock exchange, station, port, supermarket,
Telecommunication, school, monitor, restaurant, entertainment, etc.
C: Models P8, P10, P12, P12.5, P16, P20, P25., P31.25mm, led display, led module, LED panel
Characteristic
High brightness
Uniform color, reliable function, long life span.
Widely used in indoor
Good consistency, excellent visual effect.
High resolution,
Big viewing angle,
Rugged,
Vivid mixture color effect,
Color consistency.
| Technique | SMD |
| Pixel structure | 1R1G1B 3in1 |
| Pixel pitch | 4mm |
| Pixel density | 62, 500 dots/Sq. m. |
| Luminance | 2, 500cd/Sq. m. |
| Module dimension | 128mm(W) * 64mm(H) |
| Module resolution | 32 pixel(W) * 16 pixelmm(H) |
| Cabinet dimension | 512 * 512mm |
| Cabinet resolution | 128 * 128 |
| Cabinet area | 0.262 sq. meter |
| Optimal visual distance | > 3m |
| Visual angel | 140 degree (H/V) |
| Max power consumption | ≤ 2600w /Sq. m. |
| Average power consumption | ≤ 850w /Sq. m. |
| Brightness adjustment | Adjust according to the enviroment |
| brightness software (0%-100%adjustable) |
| Gray scale | point by point 4096 gray gradelevels of |
| each color, 16 bits γ correction avilable |
| Drive mode | 1/8 dynamic scan, constant current |
| Frame frequency | ≥ 60HZ |
| Refresh frequency | ≥ 480HZ |
| Input voltage | AC 90~260 volts |
| Operation temperature | -40° C~ +60° C |
| Operation humidity | 10%~90% |
| Input signal | video, s-videl, RGB digital signal etc. |
| Inout signal | S-video, RF, RGB, Yuv, YC, composite^ |
| Control system | DVI card + master control card + receiver card |
| MTBF | > 5000 hrs |
| Life span (50% brightness) | 100, 000 hrs |
| Malfunction dot rate | 1/10000 |
| Ingress protection rate | IP31 |
| Cabinet material | Epoxy paint coated, aluminum / iron |
| Application: | Rental / Permanent installation available |
