| Prod Model: |
IFCT-20T |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certification: |
CE |
| Condition: |
New |
| Ice Shape: |
Flake Ice |
Product Description
ICESTA high quality concrete cooling ice maker machine heavy duty
Concrete cooling systems:
a. Flake ice machine
b. Ice machine touch screens
c. Ice Rake hoist assembly
d. Discharge screw ice conveyor and pneumatic delivering system
e. Ice weighing system
f. Automatic ice storage bin
Product details:
TOP-Quality Ice Making Evaporator (Drum)
*UNIQUE Strict ICESTA quality control system (ERP SYSTEM controlled)
*Delicate welding technics with X-RAY. / Never leak
*SS 304 (stainless steel) Ice making drum (generator)
*All the material meet the HACCP request.
*Stainless steel cutters.
*Energy-efficient & high-sufficiency for ice production
----With the unique water distribution pan and air mouth, pure water evenly flows to the tube wall of the evaporator spirally, which improves the efficiency of heat transfer.
----As soon as ice off, the water of low temp. is using for ice-making, which saving energy & increasing the drum volume of production of ice
----Air pressure control excludes the risk of rupture of the evaporator drum. .
BITZER Refrigeration System
*Superb Stability and reliability, long use life.
*Energy-efficient
----Refrigeration can be used many times due to the tight, high quality refrigeration system
Rake Hoist assembly
ICESTA rake hoist system is composed by reducer with monitor, chain wheels, chains, bearings, steel rope wheels, supporting mechanism. The chains are driven by the chain wheels that are moved by the reducer with monitor, and the moving chains will in the turn move the steel rope wheels, with whose friction, the steel ropes are to move the ice rake mechanism up and down.
Advantages of ICETA patented ice rake assembly:
1. The design is the first type ever found in the market
2. The design simplifies the rake and hoist assembly and brings down the fabrication cost
3. The design reduces chances of maintenance by using fewer chains and chain wheels
4. The design is more compact and saves space which is used for ice storing
5. The design has included a balanced steel rope structure, which makes the rake assembly move more smoothly and stably
Materials for this assembly can be stainless steel or galvanized steel for different industries.
Discharge screw conveyor
1. Single discharge screw is used for smaller quantity of ice discharge for smaller ice storing bin.
2. Dual discharge screws are used for bigger quantity of ice discharge for bigger ice storing bin.
Pneumatic delivering system
A pneumatic delivering system is normally used for long distance ice conveying and is normally composed by the following components:
1. Metering screw conveyor with lump breaker and drive assembly
2. Blower unit with monitor
3. Air chiller with condensing unit
4. Conveying valve
5. Electrical control panel
6. Diverter valves
7. Line couplings, conveying lines, elbows(all shipped loose fir field installation)
8. Cyclone receiver
Ice weighing system
An intelligent and accurate ice weighing system is crucial for correct ice dosing. ICESTA is using world renowned scale which is the key component for this ice weighing system. An ice weighing system normally comprises of the following:
1. Scale 2. Ice weighing (Pneumatic hopper or buffer tank) 3. Analogue-to-digital data decoder
|
Model |
IFCT-20T |
IFCT-30T |
IFCT-40T |
IFCT-50T |
IFCT-60T |
IFCT-80T |
|
Daily Output(T/day) |
20 |
30 |
40 |
50 |
60 |
80 |
|
Cooling capacity(KW) |
118 |
200 |
236 |
320 |
345 |
472 |
|
Container type |
20 |
40 |
40 |
40 |
40 |
40 |
Dimension(mm) |
L |
6100 |
12200 |
12200 |
12200 |
12200 |
12200 |
|
W |
2440 |
2440 |
2440 |
2440 |
2440 |
2440 |
|
H |
2590 |
2590 |
2590 |
2590 |
2590 |
2590 |
