Hotel Using Granular Ice Machine
| Price: |
US $ 30250-30335/Piece |
| Trade Terms: |
FOB,CIP,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Paypal,Money Gram |
| Prod Model: |
NB2T-R2W |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Capacity(Kg/24h): |
2000 |
| Ice: |
Granular |
| Size (Mm): |
1750mm X 1510mm X 2040mm |
| Weight: |
3100 |
| Cube Ice Weight Density: |
500~550kg/M3 |
| Control: |
Electric |
| Power: |
>400W |
| Structure: |
Integral Type |
| Material: |
Stainless Steel |
| Application: |
Household |
| Condensing Mode: |
Air-Cooled |
| Filtering Device: |
With Filtering Device |
| Automatic Cleaning Device: |
With Automatic Cleaning Device |
| Ice Shape: |
Cube, Tube, Flake, Plate, Snow, Block, Graular |
Product Description
Granular ice machine
Applications:
Edible granular ice machine is one type of ice making machines. Because the ice shape is the grain type, so it's called granular ice. In the market it's the smallest type of ice, melting resistance best . Suitable for drinking supplies modulation, decoration, food preservation and so on, so it is mostly the edible ice.
2T/24H granular ice maker
Technical scheme:
NO. |
Parameters |
Technical data |
1 |
Model |
NB2T-R2W |
2 |
Evaporating temp. |
-10ºC |
3 |
Condenser temp |
+40ºC |
4 |
Control system |
PLC micro-computer control |
5 |
Voltage |
220V/3Phase/60Hz |
6 |
Cube ice weight density |
500~550kg/m3 |
7 |
Power consumption |
80KW~85KW/ton |
8 |
Measurement |
Cube ice machine |
Machine:1750mm x 1510mm x 2040mm |
Cube ice |
22mm x 22mm x 22mm
or 29mm x 29mm x 22mm |
9 |
Noise |
55dB |
10 |
Refrigerant |
R22 |
11 |
Evaporating temp. |
-15ºC |
12 |
Condenser temp |
+40ºC |
13 |
Input water temp. |
28ºC |
14 |
Ambient temp. |
40ºC |
15 |
Compressor |
Model |
Frascold |
Brand name |
Frascold |
Amount |
1 |
Type |
Q7-33.1 |
Power |
16.78KW |
16 |
Gear motor |
0.75KW |
17 |
Total Power of cooling fan |
0.55KW |
18 |
Cooling water pump |
2.2KW |
19 |
Power of circulating water pump |
0.75KW
|
3T/24H granular ice maker
Technical scheme:
NO. |
Parameters |
Technical data |
1 |
Model |
NB3T-R2W |
2 |
Evaporating temp. |
-10ºC |
3 |
Condenser temp |
+40ºC |
4 |
Control system |
PLC micro-computer control |
5 |
Voltage |
220V/3Phase/60Hz |
6 |
Cube ice weight density |
500~550kg/m3 |
7 |
Power consumption |
80KW~85KW/ton |
8 |
Measurement |
Cube ice machine |
Machine:1980mm x 1630mm x 1840mm |
Cube ice |
22mm x 22mm x 22mm
or 29mm x 29mm x 22mm |
9 |
Noise |
55dB |
10 |
Refrigerant |
R22 |
11 |
Evaporating temp. |
-15ºC |
12 |
Condenser temp |
+40ºC |
13 |
Input water temp. |
28ºC |
14 |
Ambient temp. |
40ºC |
15 |
Compressor |
Model |
Frascold |
Brand name |
Frascold |
Amount |
1 |
Type |
S15- 51Y |
Power |
24.04KW |
16 |
Total Power of cooling fan |
0.92KW |
17 |
Deceleration motor power |
0.75KW |
18 |
Cooling water pump power |
2.2KW |
19 |
Power of circulating water pump |
0.75KW |
20 |
Evaporator |
Type |
cube type |
Quantity |
12 pieces
|
