| Prod Model: |
Galaxias-12 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Pixel Configuration: |
1R,1G,1B |
| Scanning Mode: |
1/8 Scan |
| System Operating Platform: |
WIN2000 |
| Display Type: |
LED Video Display |
| Application: |
Stage Performance |
| IP Rating: |
IP43 |
| Certification: |
RoHS |
| Pixel Pitch: |
12.5mm |
| Pixel Density: |
6400 Dots/Sq.M |
Product Description
| Model No | Galaxias P3 | Galaxias P4 | Galaxias P6 | Galaxias P7 | Galaxias P9 | Galaxias P12 | Galaxias P16 |
| Pixel Pitch | 3.90625mm | 4.6mm | 6.25mm | 7.8125mm | 9.375mm | 12.5mm | 16mm |
| Density | 65536 | 45512 Pixel/m² | 27778 Pixel/m² | 16384 Pixel/m² | 11378Pixel/m² | 6400Pixel/m² | 3907Pixel/m² |
| Brightness (White) | 1800 nit | 2800 nit | 2650 nit | 2600 nit | 2560 nit | 2500 nit | 2500 nit |
|
| Optima visual distance | 3 m | 4 m | 5 m | 6 m | 7 m | 9 m | 12 m |
|
| Max.Power Consumption | 280 W/m² | 280 W/m² | 280W/m² | 290W/m² | 300W/m² | 310W/m² | 320W/m² |
|
| Recommendation size( can be customized) | W=625mm | W=600mm | W=800mm | W=1000mm | W=600mm | W=800mm | W=1024mm |
| L=1375mm | L=1200mm | L=1600mm | L=2000mm | L=2400mm | L=3200mm | L=2560mm |
| T=25mm | T=25mm | T= 25mm | T= 26mm | T= 25mm | T=28mm | T=28mm |
| Weight | 11.5 kg/sq.m | 11.5 kg/sq.m | 11.8kg/sq.m | 12kg/sq.m | 11.5kg/sq.m | 9.8 kg/sq.m | 9.2kg/sq.m |
| Youtube Video Links | Galaxias P3 | youtu.be/f7arteblPQA |
| Galaxias P4 | youtu.be/KHGqiCmbOWI |
| Galaxias P6 | youtu.be/0y4LmJh6YU4 |
| Galaxias P7 | youtu.be/s-VbVYPtl_c |
| Galaxias P9 | youtu.be/SvtWyx14izs |
| Galaxias P12 | youtu.be/KfMcjBgU6nE |
| Galaxias P16 | youtu.be/8pppCLcBWew |
Technical Parameters:
Resolution: 12.5mm pitch
Density: 6400 dots/SQ. M
Pixel: RGB 3-in-1 LED
Bit depth per color: 16 bit
Bit depth per pixel: 48 bit
Viewing angle: 120º × 120º
Service life: 80, 000 hours
Brightness (white): 1650 nits
Brightness level: 16 levels
Fresh frequency: 60Hz
Innovation: ≥ 10, 000Hz
Drive mode: Constant current
Control mode: VGA synchronous display
Display mode: 1280× 1024
Display port: DVI
Working voltage: 90~264VAC 50/60Hz
Power consumed: 65W/ SQ. M
Face material: DFR Velevet Drapery
Weight: 9.0kg/ SQ. M
Weather rating: IP 44
Optimal visual distance: 8m
Ambient relative humidity: 10%~90%
Working temperature: -10 º ~50 º
Package: Flight case optional
Recommendation Size: 800mm width X 3200mm height
Installation: Hang
Control system: Power-600, Power-1200
Safety certificate: CE, FCC
Huasun Technology Co., Ltd. is a high-tech enterprise that is engaged in the researching, developing, producing, marketing, and engineer service of LED display and LED lighting. It has been grown in Beijing, capital of China, for over ten years. The main products and services include LED display system, LED digital stage system, LED lighting system. With a business principle of technological innovation and professional service, the company commits to provide high-quality LED products and solutions for all clients.
The company has a R&D team made up of senior engineers. Taking advantage of the technological and cultural resource in the Capital of China, working together with experts in mechanism, optics, and electronics from the main universities, the team is devoted to the research and application of multimedia technology and has gained the leading position in product design, software development, mechanical design and optical application. The company has own many national invention patents in LED display technology. Flexible LED display, one of our patents, is a landmark product in the development of LED display. It is widely used by the clients from all over the world for the advantages of compact size, light weight, and easy installation. We always keep in mind that the mission and responsibility of the enterprise is to change the world by pioneer spirit and innovative product in a technology high speed age. We are always proud of it.
Welcome to future of Huasun: A brighten future.
