High Vacuum Transformer Oil Purifier
| Price: |
US $ 5000-15000/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T |
| Prod Model: |
ZYD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model No: |
Zyd |
| 1 St Stage Pump: |
Leybold Vacuum Pump |
| 2ND Stage Pump: |
Booster Roots Pump |
| Oil Pump: |
Viking |
| Dielectric Strength: |
>70kv |
| Ultimate Vacuum: |
5PA |
| Working Vacuum: |
<133PA |
| Power Supply: |
According to Customers' Power Supply |
| Warranty: |
1 Year Under Normal Operation |
| Application: |
Lubrication Oil |
| Structure: |
Mobile |
| Type: |
Suction Filter |
| Mechanical Principle: |
Vacuum |
| Usage: |
Oil and Gas Separation,Oil-Water Separator,Solid |
Product Description
Application:ZYD-I Double stages vacuum transformer oil filtration machine is used mainly applied in power plant, power station, transformer factory, electric power company, power transformation, metallurgy, petrifaction, machinery, traffic, railway and so on.ZYD-I can remove particles, dewater, degas from the old and new insulating oil. Especially for the 110KV-500KV large-scale transformer station, ZYD-I oil filtration machine is particularly suitable for treating high-grade transformer oil, super-voltage transformer oil and new transformer oil.Function:A: removing the moisture. The final treated oil can achieve less than 3ppmB: degassing. The final treated oil can achieve less than 0.1%;C: removing particles. The final treated oil can achieve NAS2 Grade (Cleanliness Grade).D: vacuum oil injectingE: vacuum drying equipment for transformers ZANYO outstanding features:- Evaporation chamber is horizontal, and oil chamber is vertical, the two chambers are separated, therefore the maximum utilization of degassing chamber space.
- Unique technology: Atomizer is placed upside down, the oil droplet average diameter less than 30µm, to increase evaporation area and extend the degassing time. Comparing to the one- vertical chamber machine, ZYD-I filtration system is 3 -fold and 5-fold quickly and effectively thank old machine.
Feature- Double stage vacuum: high pumping speed, advanced dehydration and degasification system, Duplex-Stereo film evaporation technology, can remove particles, water, degas and hydrocarbon quickly and effectively, to improve the flash point and dielectric strength.
- Used for transformer installation and inspection, vacuum oil injecting and vacuum drying equipment for transformers.
- Precise oil filtration system, superior oil filter, Multi-stage precision filtration system, can remove mechanical particles effectively.
- Advanced constant temperature control system, auto evel control system,auto defoaming system, pressure protecting system to make sure the high-performance of the machine
- Vacuum purification online work, unattended operation.
- Humanization design, low noise, simple operation, long interval of maintenance time and low energy consumption.
- Be equipped interlocked protecting system, oil discharge system, vacuum system, interlocked heating system, to make sure the machine run smoothly.
- Adopt short-circuit, Over voltage, Low voltage, Low battery voltage, Surge protection, loss phase protection
Optional PartsPLC control system, dynamic displayOnline moisture tester Frequency changerFlow meterStructure:Mobile type, stationary type, trailer, enclosed doors, open typeTechnical Parameters| Index name | ZYD-I | 30 | 50 | 80 | 100 | 125 | 150 | 200 | 250 | 300 |
| Flow rate | L/min | 30 | 50 | 80 | 100 | 125 | 150 | 200 | 250 | 300 |
| Ultimate vacuum | Pa | ≤5 |
| Working vacuum | pa | ≤133 |
| Working pressure | Mpa | ≤0.3 |
| Working Temperature | ºC | 30-80 |
| Power supply | | 380V 50HZ 3Ph (According to customers' power supply) |
| Continuous working time | H | ≥200 |
| Working noise | dB | ≤65 |
| Heating power | KW | 24 | 30 | 48 | 60 | 72 | 90 | 120 | 150 | 180 |
| Total power | KW | 28.5 | 34.5 | 53 | 68 | 80 | 99 | 132 | 165 | 198 |
Pipe
diameter | Inlet | mm | 32 | 32 | 45 | 45 | 45 | 58 | 58 | 75 | 75 |
| Out | mm | 32 | 32 | 45 | 45 | 45 | 58 | 58 | 75 | 75 |
Machine
dimension | L | mm | 1450 | 1450 | 1750 | 1750 | 1800 | 1950 | 1950 | 2050 | 2100 |
| W | mm | 850 | 1250 | 1250 | 1450 | 1460 | 1550 | 1850 | 1850 | 1950 |
| H | mm | 1400 | 1500 | 1500 | 1800 | 1850 | 1850 | 2150 | 2250 | 2280 |
| | | | | | | | | | | | | | |
The final treated oil index: | Item | Guarantee indexes |
| Moisture content | ≤3PPM |
| Impurity size | ≤1 micron |
| Gas content | ≤0.1% |
| Dielectric strength | 70kv |
Long-term quality warranty of 2 years.
Chongqing Zanyo Electromechanical And Machinery Co., Ltd is located in Chongqing, China, the beautiful mountain city of. China. Chongqing city is called "the China filtration equipment & production base". ZANYO is a professional high-tech enterprise which insists on the specialized in the research, design, production, sale and service of oil filtration equipments for these years. Our new techniques for the "T" type evaporator and "S" type heater, thermal recovery system are very popular and we get very good feedback from customers. At the same time, we also design and provide the power equipments, oil testing equipments. Products are well sold at home and abroad and deeply favored by broad masses of clients!
To the company, we spare no effort to seek innovation and produce the stable performance, excellent products under the theory of "people-oriented, energy conservation, environmental protection, customer first, the benefit of future generations". Over the years, we win favorable comments in this circle of filtration. The leading products are transformer oil filtration machine, insulating oil purifier, lubricating oil purification system, hydraulic oil filter machine, turbine oil treatment machine, used motor oil recycling system and other industrial oil filtration machines. We also can provide the oil testers for our customers. The products are widely used in electric power, plant, mining, petroleum, chemical, metallurgy, waste disposal and other industries.
Since the establishment of the factory, we engaged in interior market for nearly ten year. From 2012, we exported the machines to foreign markets. We ZANYO factory always adhere to the basic principles: High quality machinery production.
Culture:
Our purpose: Quality first, Credibility first, Service first", to reach energy-saving emission reduction and win-win situation.
Our value: Users first, Brand success, Repay society
Our belief: Earnest, Innovation, Brave pursuit, Trustworthiness
Our dream: To endeavor to accomplish greater technological breakthrough; To endeavor to supply more environmental, more safely, and more efficient products and schemes; To endeavor to perform to the best and repay society.
Welcome domestic and international old and new customers to come to discuss business, to guidance, and we sincerely look forward to the parties and knowledgeable people work together to create brilliant!
Our products list as following:
ZYS-high effective vacuum transformer oil purification machine
ZYD-I, ZYD-II Double stages insulating oil purifier
ZYM-Mobile/trailer type transformer oil treatment equipment
ZYAD-Air dryer for drying electric equipments
ZYT-Turbine oil filtration machine
ZYJ-Coalescence and separating oil filter
ZYL-Lubricating oil purifier/hydraulic oil treatment device
ZYK- Phosphate ester fire-resistant oil purification machine
ZYR-Transformer oil regeneration device
ZYP-Plate pressure oil filter
ZYJL-Portable oil purifier
ZY-IIJ-II-BDV oil tester, insulating oil dielectric strength tester
ZYMMT-Oil moisture sensor, water content sensor
ZYRS-Engine oil regeneration system
ZYL-D- oil decoloring machine/oil recycling machine
