High Quality X86- Touch Transparent LCD Display for Advertising

Network Support:	Ethernet
Light Transmittance:	90%
Display Ration:	16:09
Surface Treatment:	Hard Coating (3 H) and Antidinic Plariser
Communication Interface:	USB
Response Speed:	< 20 Ms
Tube Chip Color:	Full Color
Display Function:	Video Display
Pixel Pitch:	6mm
Pixel Configuration:	1R,1G,1B
Pixel Density:	27,777 dots / m²
Scanning Mode:	1/8 Scan
Display Type:	LED Video Display
Application:	Advertising
IP Rating:	IP43
System Operating Platform:	Windows XP,Windows 7,Windows 8,Linux

Product Description

Main Hardware Indicators
Transparent Displays	Panel size	10.4	21.5	32	42	47	55	65	84
	Display size(mm)	211*158	476*268	698*392	927*522	1039*584	1209*680	1428*803	1860*1046
	Resolution Ratio	1024*768	1920*1080	1920*1080	1920*1080	1920*1080	1920*1080	1920*1080	3840*2160
	Light Transmittance	90%
	Viewing Angle	70/70/75/75	89/89/89/89	89/89/89/89	89/89/89/89	89/89/89/89	89/89/89/89	88/88/88/88	89/89/89/89
	U/D/L/R
	Display Ration	16:09
	Surface Treatment	Hard coating (3 H) and antidinic plariser
Whole machine size		It can be customized according to customer's requirements
PC configuration (according to customer requirements)		CPU 1037U, CPU Frequency 1.8 GHzCPU 1037 u, faster - 1.8 GHz
		1 * SO - DIMM, DDR3 1333/1066 MHZ, maximum support 8 G, the standard configuration 4G
		1 * SO - DIMM, DDR3 1333/1066 MHZ, maximum support 8 G, the standard configuration 4G
		Hard disk   2*SATA 2.0,2*MINI-PCIE, standard configuration 64G SDDSATA
		Audio interface, integration Realtek ALC662HD digital audio decoder, support t Line - out, MIC - in  interface
Audio , video and image format		Video broadcast formats including MPEG4, MPEG2, MPEG1, MOV, AVI, WMV, TS, FLASH, etc
		Audio formats: WAV, MP3, ACC, etc
		Image formats: JPEG, PNG, BMP, GIF, etc
		Other formats: WORD, PowerPoint, EXCEL, etc
I/O Interface		Four USB interface, can connect USB keyboard and mouse and USB flash drive
		A Realtec 8111E gigabit RJ45 interface
		A HDMI input interface
		A VGA input interface
		Two standard single audio interface (MIC and Lineout)
Network Support		Ethernet,  support WIFI, 3 G wireless peripherals extension
Operating System		Windows XP,Windows 7,Windows 8,Linux
Touch Screen		Inductive way: built-in infrared induction multi-touch technology
		Touch mode: opaque objects such as finger and pen .
		interpolated resolution : 32768 * 32768
		Communication interface: USB
		Clicks in theroy: unlimited times
		Response speed: < 20 ms

Function of Information release system

1.Flexible B/S architecture, the headquarters unified control, subordinate agency authorization management,

   playing terminal according to the schedule (real-time + local play)

2.Support custom schedule ,playing function, emergency insert function, periodic playing function, default

   playing function

3.Specify send:  the programs real-time or specified time  sent to the designated end or group;

4.Update:  playing terminal can set by designated terminal or ID to update their programs;

5.File encryption: file encryption for all data transmission, providing end-to-end MD5 information security

6.Transmission control: support breakpoint continuingly, P2P download, regular download, real-time download

   and flow control.

7.Support weather, time, stock, foreign exchange, flights, TV and so on dynamic real-time components

8.Support for scrolling marquee, free split screen

9.Support the broadcast schedule, playlists function

10.Rigorous approval process, can be set level 1, level 2, level 3 of approval administrator

11.Comprehensive approval setting, approval from the lower to upper application, and can be set by

     emergency degree

12.Perfect approval operation:when the superior approval the programms, the broadcast content, playing time,

     and playing site can be auditing  and modified, evaluate whether the program is approved.


Trade Terms:

1. Payment: 30% before production ,full payment before shipping by TT or Paypal.
2. Delivery Time:2-5 days for sample, mass production depends on the QTY.
3. MOQ: 500PC.
4. Customers can freely choose the shipping way, TNT, DHL, FedEx, by air or by sea etc.
    We have professional freight forwarders, on the transportation we will not earn customers
    one penny of profit. Of course customers also could use your own freight forwarders, we
    will to fully cooperate with you.
5. Shipping port: Shenzhen Port

Our service:

1.Your inquiry related to our products or prices will be replied in 24hours.
2. Professional service will surely be offered by the well-trained and experienced staffs
3. Protection of your sales area, ideas of design and all your private information.
