| Prod Model: |
BTH-002 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Frequency Range: |
2.4~2.4835GHz |
| Storage Channel: |
79 |
| Talk Range: |
800 |
| RF Sensitivity: |
-90db |
| Operation Range: |
10m |
| Mic Type: |
DSP Noise Cancellation Mic |
| Bluetooth Profile: |
Hsp, Hfp, A2dp, Avrcp |
| Use: |
Mobile Phone, Portable Audio Player |
| Color: |
Black |
| Style: |
Handheld Microphone |
| Application: |
Voice |
| Sound Channel: |
Stereo |
| Signal Transmission: |
Wireless |
| Wireless Technology: |
DSP Digital |
| Directivity: |
Uni-direction |
| Transducer Principle: |
Electrodynamic Microphone |
| Output Impedance: |
50-1000Ω |
| Sound Field Force: |
Combined Type |
| Connector(',s): |
USB |
Product Description
Feature of Push to talk PTT mic/microphone:
1. BT3.0 AGHSP, AGHFP Profiles Supported
2. Can connect with mobile phone for calls handling and stereo music
3. Switch to mono and stereo
4. PTT button support
5. Can connect with various radio Bluetooth adapter
6. Support 3.5mm headset connector
7. DSP noise suppression, Crystal Voice Quality
8. Compatibility with various phone
9. Long life lithium battery (500mA/3.7v)
10. 1 year warranty
Technique specification:
| Bluetooth Chip | CSR BC5 MM |
| Bluetooth Version | Bluetooth 3.0 |
| Bluetooth Profiles | HSP,HFP,A2DP,AVRCP |
| Bluetooth RF Spec | Class 2 |
| RF Power | 6dB |
| RF Sensitivity | -90db |
| Operation Range | 10 Meters |
| RF Frequency | 2.4~2.4835GHz |
| Audio Input 3dB Bandwidth | 20kHz |
| THD+N @ 30mV rms input | 0.0005 |
| Audio Input SNR @ 8kHz | 79dB |
| Audio Out THD+N@f =1kHz,R = 8ohm | 0.006 |
| CMMR | 50dB |
| Audio Output Bandwidth | 20Hz~20kHz |
| Average Talking Current @ 8Ω Load | 200mA |
| Average Standby Current | 6mA |
| Operating temperature | -15°C ~50 °C |
| Storage Temperature | -25°C ~60°C |
