| Prod Model: |
A140 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Min. Hole: |
0.1mm(4mil) |
| Min. Line Width: |
4mil |
| Copper Thickness: |
0.5oz-6oz |
| Board Thickness: |
0.1 to 6.0mm(4 to 240mil) |
| Layers: |
Double-Layer |
| Certification: |
UL |
| Base Material: |
FR-4 |
| Mode Of Production: |
SMT |
| Metal Coating: |
Copper |
| Customized: |
Customized |
| Condition: |
New |
Product Description
E-SOURCES Three Advantages
1) Integrate Industry chain, we have 3 our own and holding companies for manufacturing components and PCBs. We can do PCB, PCBA, ODM, OEM and EMS one stop service, can ensure high quality and low price.
2) Professional, we have imported and advanced WORLD FAMOUS BRAND producing and inspection equipment. We have 10 experienced engineers to keep our process and technology support, we have our own corporation culture and management system ISO9001:2008 to courage our stuffs high efficiency.
3) Excellent Service, our experienced engineers and advanced equipments can control the producing, inspection and after service to satisfy our customers need, and our dedicate sales team can provide 24 hours service.
Competitive Advantage:
| Process/Spec. | E-SOURCES | Features | Normal Company | Features |
| Print | Japan SUNEAST,
GKG printer | High precision alignment with four Mark points,Prevent the PCB deformation,Adjust different thickness of PCB,Short printing time and printing cycle Bare,board dimension:48x48~759x610mm | local machine |
Semi-automatic,alignment
with two Mark points,
Bare board dimension:
60x60~759x610mm |
SPI | Korea KOHYOUNG 3D SPI machine |
Inspect the PBC automatically,High speed,High precision,High Flexible | local machine | Inspect the PBC Semi-automatically,Normal speed and Normal precision |
SMT | SAMSUNG 481,421,411 |
Dual-track chip mounter,
High speed and high precision,
Short printing time and printing cycle,Mount accuracy:+/-0.1mm | local machine | Monorail chip mounter,Normal speed and normal precision,Mount accuracy:+/-0.3mm |
Solder | U.S.HELLER,BTU,
German REHM Reflow Owen | Ten heating zones,Temperature accuracy:±1°C,PCB size:48x48~
759x610mm,Professional wind wheel design with stable blowing speed | local machine | Seven heating zones,Temperature accuracy:±1.5°C,PCB size:0x60~759x610mm |
| DIP | Automatic manual DIP | Automatic,High speed | local machine | Semi-automatic,Normal speed |
| AOI | Japan OMRON online and offline AOI machine | Good and defective PCBs can be stored separated automatically with rack,High precision,High stability | local machine | Semi-automatic |
| Process/Spec. | E-SOURCES Feature | Normal Company |
| Package | strict process system | normal packing |
| Number of layer: | 1-36 L | 1-16 L |
| Type of assembly: | SMT and DIP | SMT and DIP |
| Type of SMT : | QFP, SOP, SOJ, TSOP, TSSOP, QFN,
POP,BGA,PBGA and UBGA | QFP, SOP, QFN, |
| Solder: | Lead Free (11 zones reflow soldering) | 7 zones reflow soldering |
| Testing: | 100% AOI,3D SPI, ICT, Electronic test,
Visual inspection, Functional test | Visual inspection, Functional test |
| Bare board dimension: | 48x48~759x610mm |
|
| Min. component size: | 1005 | 0201 |
| Min. IC space: | 0.25mm | 0.3mm |
| Min. pitch of BGA: | 0.4mm | 1mm-3mm |
| Min. pitch of QFN: | 0.4mm | \ |
| Printed precision: | 0.01mm | 0.015mm |
| SMT precision: | 0.02mm | 0.03mm |
| Pass rate | 85% | 50%-70% |
| Remote monitoring by clients | Yes | No |
| Flexibility | Max 74x74mm. Equipment has 4
robot arms, various head units. | Max size 7070. Has 2 robot arms. |
| Component suppliers | Long time strategy partners
with world-class component
suppliers. Steady and low prices. | Often changes component suppliers.
Quality is unstable. |
| Warehouse | Constant temperature, dustproof,
moistureproof, anti-static. | Common Warehouse. |
| Sales team | Bacholer degree of international
trade or Englsih related majors. | High school graduation certificate or above |
FAQ
Q1:What is your products range?
§.We provide PCBA for IT, communication, tablet PCs, smart cards, financial equipments, auto electronics, GPS modules. We can do OEM,ODM.
Q2:Do you provide material sourcing service?
§.We have our own industry chain. Our material sources are stable, high quality and low prices.
Q3:Do you provide complete unit assembly service?
§.Yes, include plastics, metal box, Coil, cable inside etc
Q4:What is your payment term ?
§.T/T or L/C at sight.and It ' s negotiable
Q5:What is you trade term?
§.FOB Guangzhou/Shenzhen port.
Q6:Do your pay for import taxes and duty?
§.No, they are not included. Clients should pay for them.
Q7:How long do you need to make samples? And how about the lead time?
§.About 15-20 days for samples, and about 45 days bulk production after get your payment
Q8:How do you make sure product quality?
§.We have 3D SPI, AOI,and we do ICT, Electronic test, Visual inspection, Functional test.
Q9:What about your shipping method?
§.We suggest you using our DHL, UPS, FedEx, TNT forwarder. By EMS (Usually for Russia Clients), price is high.
Q10:Can we visit your factory?
§.Yes, welcome to visit us any time.
