| Prod Model: |
HC1500-LBA2R |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Usage: |
for Refrigerate, for Air Conditioner, for Manufa |
| Cooling Method: |
Direct Cooling |
| Type: |
Cabinet Air Conditioner |
| Operating Voltage: |
230 VAC |
| Mounting: |
Wall/Window Mount |
| Certification: |
CE |
| Condition: |
New |
Product Description
Cabinet air conditioning can regulate temperature, relative humidity in the cabinet. Various physical states of cooling space can be monitored remotely on line, and the parameters can be adjusted remotely, so temperature and humidity in the cabinet will be controlled effectively.
1.features
1.1 can effectively prevent from charged particles, sparks, dust, water vapor and corrosive gases .
1.2 lightning protection
1.3 Remote online intelligent monitoring system
1.4 High protection class ( Ip55).
2.Installation -half embedded
3.Application
Communication Cabinet, Electric control cabinet, Charging stations.
4.Specification
Model |
HC500-LBA2R |
HC1000-LBA2R |
HC1500-LBA2R |
HC2000-LBA2R |
HC2500-LBA2R |
refrigerating capacity |
W |
500 |
1000 |
1500 |
2000 |
2500 |
Rated voltage |
V |
220V/110V |
frequency |
HZ |
50HZ/60HZ |
input power |
W |
240 |
622 |
622 |
885 |
1157 |
Rated current |
A |
1.2 |
2.8 |
2.8 |
4.2 |
5.6 |
Installation Dimension |
L(mm)*H(mm) |
323*550 |
375*905 |
455*755 |
455*755 |
410*1110 |
Outer Dimension |
L |
mm |
359 |
415 |
498 |
498 |
488 |
W |
mm |
146.5 |
165 |
184.5 |
184.5 |
220 |
H |
mm |
586.5 |
945 |
798 |
798 |
1188 |
Noise |
dB |
65 |
protection class |
Inside |
IP30 |
Outside |
IP54 |
Refrigerant |
R134a/R22 |
