| Prod Model: |
LWS-2030PME-4R |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Item Name: |
Mobile Phone Touch Screen Screen Printing Machine |
| Printing Color: |
1 |
| Continue Sports: |
Can |
| Every Parts Delay Time: |
Can |
| Printing Speed: |
1300 Times/ Hour |
| Type: |
Vertical Screen Printing Machine |
| Style: |
Screen-process Printing Press |
| Structure: |
Rotary Printing Press |
| Color & Page: |
Single-Colour Printing Press |
| Print Interface: |
No Need |
| System Supported: |
No Need |
Product Description
high precision Mobile phone touch screen screen printing machine with conveyor
Products instruction:
LWS-2030PME-4R precision conveyor screen printing machine main apply to Mobile phone touch screen, light guide OGS / TP / CG / LTD glass, PCB, LCD, liquid green oil,EL, thin film, keyboard, acrylic, mobile phone panels, touch panels, light guide plate, diffusion chip, nameplate signs, ceramics, stationery and small pieces of film / sheet / Precision Screen Printing of the plate-shaped products, such as flexible printed circuit (FPC), in-mold decoration (IMD), film button (Membrane Switch), and other biological test piece ....... product precision flat screen printing.
Screen printing machine parameter:
1 Printing color: 1 color
2 Single Cycle: Can
3 Continue sports: can
4 Counter: can
5 Every parts delay time: can
6 Printing speed: 1300 times/ hour
7 Max screen frame size: 450x 650mm
8 Max printing area: 180mm x 250mm
9 Worktable size: 200mmx 300mm
10 Conveyor diameter: dia.845mm
11 Station quantity: 4 pieces
12 Robot stroke: 500mm
13 The max objects height: 80mm
14 Screen frame up stroke: 200mm
15 Scraper stroke: 350mm
16 Scraper/ squeegee up/down stroke: 30mm
17 Worktable Vertical and horizontal adjustment amount: +-6mm
18 Feeding way: Vacuum Adsorption/ Finger gripping
19 Lift driver: Servo motor
20 Control system: PLC
21 Control motor: DC24V
22 Control voltage: AC220V 50/ 60hz
23 Power: 2.2kw
24 Working air pressure: 0.4-0.6Mpa
25 Air consumption/ circle: 3.0L
26 Machine dimension: 1160 (L)X 1450MM(W)X 1600MM(H)
27 Weight: 560kgs
Remark:
1 Delivery Time: 20 days when receive your payment.
2 Package: plywood case
3 Warranty: 1 year
