High Power PRO Audio Dual 12" 3-Way Professional Line Array (CA-2812)
| Price: |
US $ 300-600/Piece |
| Trade Terms: |
FOB,EXW |
| Min Order: |
2/Piece |
| Pay Type: |
T/T |
| Prod Model: |
CA-2812 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Woofer Size: |
2 X 12 Inch High Power Woofers |
| MID Woofer Size: |
2 X 8 Inch Power Woofers |
| Tweeter Size: |
2 1.75 Inch High Quality Compression Driver Unit |
| Components: |
2z12"+2X6.5"+2X1.75" |
| Material: |
Plywood Cabinet |
| Type: |
Dual 12" 3-Way Line Array |
| Noise: |
<102dB |
| Hi-Fi: |
Hi-Fi |
| Operation Mode: |
Wire / Remote Control |
| Speaker Material: |
Wood |
| Application: |
Commercial |
| Certification: |
CE |
| THD: |
<0.005% |
| Activity: |
Active and Passive Available |
| Speaker System: |
Professional Performance |
Product Description
NOVA manufacture line array, pro audio, professional speaker, active speaker, passive speaker, amplifier, mixer, flightcase and woofer units.NOVA is a professional loudspeaker manufacture and exporter in China.
We make line array speaker, line array, pro audio, pro audio speaker, professional loudspeaker, professional speaker, subwoofers, subwoofer, woofers, and amplifier, flight case and racks.Specifications of CA2812 line array:
Frequency response: 45Hz-20kHz (+/- 4dB)
RMS power: HF is 150W, MF is 250W, LF is 900W
Program Power: HF is 200W, LF is 1600W
Norminal Impedance: HF is 8Ohm, MF/ LF is 4Ohm
Sensitivity: 108dB/W/M
Component: 12"X2 + 2X8" +2X1.75" horn
Dispersion angle: 90 degree X 10 degree (H X V)
Dimension: 1175 X (370 X 265) X610mm
Line array speaker system, professional audio sound equipment, PRO audio sound, PA loudspeaker system, professional speaker equipment,Line array, line array system, line array China, audio, speaker, acoustics, audio equipment, sound equipment, speakers, loudspeaker, professional speaker, professional loudspeaker, PA audio, professional audio, speaker manufacturer, loudspeaker manufactory, audio speakers, sound speakers, stereo speaker, PRO audio speaker, audio loudspeaker.
Our CA2812 line array are high power loudspeaker. With high performance, wide bandwith specification, they are suit in highest level of connect touring, stadium, large club, stage, theater and auditorium etc.| Model Number | CA2812 | CA-2212 | CA-0010 | CA008 | CA110 |
| Frequency Response | 45HZ-20KHz (-10dB) | 55HZ-19KHz (-10dB) | 120Hz-20KHz (-10dB) | 120Hz~20 KHz (3dB) | 100Hz~20 KHz (3dB) |
| 50Hz-19KHz ( ±3.5dB) | 50Hz-18KHz ( ±3.5dB) | 130Hz-19KHz (±3.5dB) |
|
|
| RMS power | HF: 100W, MF: 220W, LF:800W | HF: 150W, LF:800W | HF:80W, LF:600W | 350W | 300W |
| Program power | HF: 200W, MF: 440W, LF:1600W | HF:300W, LF:1600W | HF:160W, LF:1200W | 700W | 600W |
| Peak power | HF: 300W, MF: 660W, LF:2400W | HF:450W, LF2400W | HF:300W, LF1800W | 1050W | 900W |
| Norminal Impedance | HF:4Ohm, MF:16Ohm ,LF:4Ohm | HF:8Ohm, LF:4Ohm | HF:8Ohm, LF:4Ohm | 16Ohm | 8Ohm |
| Sensitivity | 108dB/w/m | 105dB/w/m | 101dB/W/M | 101dB/M/W | 123dB/M/W |
| Max SPL | 136DdB | 134Db | 120dB | 126B | 126B |
| Component | 2x12"+2X8"+2X2" | 2x12"+3" | 10" x2 +2" | 8" x2 +2" | 10" +2" |
| Coverage Angle | 90° H X10°V | 90° H X10°V | 90°H X10°V | 100°H X7°V | 60°H X10°V |
| Dimension | (370x265) x 1175 x 610mm | (370x270) x 920 x 570mm | (300x230)x800x445mm | (245x190)x640x335mm | (300x245)X520X350mm |
| Model number | CA-2812 |
| Frequency response | 55Hz-19KHz(-10dB) |
| 50Hz-18KHz(±3dB) |
| RMS power | 1300W |
| Program power | 2600W |
| Norminal Impedance | LF:4Ohm,MF:16Ohm,HF:16Ohm |
| Sensitivity | 108dB/W/M |
| Max SPL | 136dB |
| Component | 2x12"+2x8"+2x1.7" |
| Coverage Angles | 90H°x10°V |
| Dimenstion | (370x265)x1175x610mm |
Nova specializes in manufacturing PRO audio which including line array, professional loudspeakers & KTV, power amplifiers, mixers consoles, signal processors including equalizers, limiters/compressors, exciters, crossovers, power sequence controllers etc. To meet different customer's market, we also add producion line for woofer speakers, subwoofer speakers and flightcase for sound equipmentand professional lights and LED monitor ect.
With experienced & strong R&D department and strictly quality control managment and Satisfactory market service system and reasonable price and good quality, Our price had got high reputation in many ares.
OEM/ODM also available.
Nova will offer what you want.
Please join in NOVA family!
