| Prod Model: |
FP6000Q |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Low Impedance: |
2.67 Ohms Load Stable |
| Two Version: |
110V or 220V Are Avaliable |
| Heatsink: |
Pure Copper |
| Type: |
Professional Amplifier |
| Usage: |
KTV System |
| Used For: |
Professional |
| Tube Type: |
Transistor Amplifier |
| Function: |
Pre-amplifier |
| Sound Channel: |
4.1 |
| Output Number: |
4 |
| Voltage: |
AC 110V |
| Element Number: |
Push-Pull Amplifier |
| Conductive Mode: |
Td |
Product Description
Features
A. Very high power and channel density--2ΩStereo Power (RMS) : 1500WX4
B. Four-channel flexibility
C. NomadLink® network ready
D. Patented Class TD amplifier topology
E. Regulated Switch Mode Power Supply (R.SMPS)
F. Efficient cooling system -- Unique, lightweight Intercoller copper cooling system dissipates
more heat to allow extended peak output
G. Adjustable parameters-- Selectable Gain, scalable Voltage Peak Limiter (VPL), and
bridge-mode operation allow custom configuration for any application
H. Comprehensive protection and warning--Excessive output current, DC, high temperature, very
high frequency (VHF), short circuit, open load, mains fuse protection, and soft start
Quick detail
ITEM -- FP6000Q
Output Power -- 20-34kHz, 1W with 1 KHz
8ΩStereo Power (RMS) -- 625WX4 Dimensions(W x H x D)-- 483 x 88 x 396 mm
4ΩStereo Power (RMS) -- 1250WX4 Packing dimension -- 580 x 180 x 560 mm
2ΩStereo Power (RMS) -- 1500WX4 Net weight (kg) -- 13
8ΩBridged Power (RMS) -- 2500WX2 Gross weight (kg)--18
4ΩBridged Power (RMS) -- 3000WX2
Specification
Frequency Response(+o/-0.3dB,1W/8Ω) | 20 Hz - 34 kHz |
THD 20 Hz - 20 kHz for 1 W | <0.1% |
Signal-to-Noise Ratio | >112 dBA |
Class | TD |
Channel separation (Crosstalk) at 1 kHz | >70 dB |
Input Connectors (per channel) | 3-pin XLR, electronically balanced |
Output Connectors (per channel) | Binding Posts 2-pole |
TourClass Protection | short circuit, DC voltage, turn-on/off transient, current inrush |
Voltage Gain(dB) | 23, 26, 29, 32, 35, 38, 41, 44 dB selectable |
Input impedance | 20 Kohms |
Level adjustment (per ch.) | Front-panel potentiometer, 31 position detented from -inf to 0 dB |
Sanway Professional Audio Equipment Co., Ltd is one of the best PRO Audio suppliers in Guangzhou, China. We are a factory that specializes in research, developing, manufacturing, sales and technical and offer top quality products and service since 1997 and gained very high reputation at home and abroad.
With emphasis on quality and innovation our company has modern assembly line, strict quality control and hard working staff. We put a emphasis on purchasing the high grade raw materials to give you a high performance product. With fully trained workers we ensure that you will only get the finest quality and performance product that comes off of our assembly lines.
Our engineers and technicians have extensive experience in the PRO audio industry. Continuous researching and developing ensure that our products in high standard to give you the competitive advantage to your customers and market.
Application: Our products are suitable for various of PRO audio, entertainment and commercial uses...Such as live event performance, touring concert church, , Band, stadium, gymnasium, theaters, Cinema, concert halls, auditorium, hotel, School, discos, club, wedding, etc.
Main products: Professional Power Amplifiers; Active Speaker Module; Line Array System; Indoor & outdoor Professional Speakers; Digital Speaker Processors; Equalizer etc.
We always keep and follow the principle to do business:
The same product, we win by the quality;
The same quality, we win by the price,
The same price, we win by the service.
We sincerely hope that continuous business relationships can be established and please trust that we are always doing our best to realize good business relationships with our clients. We are constantly seeking new agents and distributors worldwide.
Don't hesitate to contact us if you are interested in any item, or should you have any special requirement, please kindly let us know directly, we will reply you as soon as possible.
