| Prod Model: |
Fox-P16 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size Of Module: |
256*256mm |
| Pixel Configuration: |
1r1g1b |
| Brightness: |
8, 000CD/Square Meter |
| Protection Degree: |
IP65 |
| Viewing Angle: |
120° |
| Refresh Rate: |
>=300Hz |
| Working Voltage: |
AC220V/110V+-10% |
| Module Resolution: |
16*16 |
| Life Span: |
100,000h |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Pitch: |
16mm |
| Pixel Configuration: |
2R, 1G, 1B |
| Display Function: |
Video Display |
| Average Power Consumption: |
600W / m² |
| Pixel Density: |
6944 dot / m² |
| Scanning Mode: |
Static Scan |
| Display Type: |
LED Video Display |
| Application: |
Advertising |
Product Description
1. ISO9001 UL, CE, SGS&RoHS
2. Vivid image and Video
3. Good after sale-sevice
4. Support various data transport
5. Durable and economic
6. High reliability, long durability
7. Wireless remote controller
Function and Technology Character
(1) Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive.
(2) Information source can be camera, video, VCD, DVD, LD, TV and so on.
(3) Clear picture without flicker and distortion.
(4) Brightness, contrast, saturation can be adjust by itself and manual.
(5) Show everything with your PC does synchronously or offline does asynchronously
(6) Super correcting technology for distortion.
(7) One interface for sound signal and two for video signal at least.
(8) Connected and controlled by PC via LAN and remote control.
(9) Multiform language editions, such as English, French, Germany, Greek, Russian and so on.
(10)Can be connected with PC and the website, and also can be controlled remotely via wireless controller
| Number | Item | P16 |
| 1 | Pixel pitch | 16mm |
| 2 | Size of modual | 256mm X 256 mm /256mm X128 mm |
| 3 | Resolution of modual | 16 X 16/16 X 8 |
| 4 | Density of pixel | 3906dots/m2 |
| 5 | Pixel configuration | 2R1G1B |
| 6 | Red wavelength | 625± 2nm |
| 7 | Green wavelength | 525± 2nm |
| 8 | Blue wavelength | 470± 2nm |
| 9 | Colors | 16777216 |
| 10 | Best viewing distance | 14-300m |
| 11 | Horizontal viewing angle | 120° |
| 12 | Maximum power consumption | ≤ 1200W/m 2 |
| 13 | Brightness | ≥ 8000cd /m 2 |
| 14 | Gray scale | 16bits per color |
| 15 | Color temperature | 6500k |
| 16 | Control method | Synchronization & Asynchronization |
| 17 | Driving method | 1/4scanning |
| 18 | Frame frequency | 60Hz |
| 19 | Refresh frequency | ≥ 300Hz |
| 20 | Working voltage | AC220V/110V± 10% |
| 21 | IP grade | IP67(adjustable) |
| 22 | Working temperature | -20° C~80° C |
| 23 | MTBF | > 10000 hours |
| 24 | Life span | > 100, 000 hours |
| 25 | Defects rate. | ≤ 0.00001(Led display line standard< 0.0001) |
| 26 | Computer operation system | Win XP/Vista/ Win 2000/WIN7ect. |
| 27 | Video signal | RF, S-Video, RGB, RGBHV, YUV, YC. ect
|
