Prod Model: |
XY-HDMI 1.3 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Connector: |
USB |
Switch: |
Without Switch |
Charging Function: |
Without Charging Function |
Product Description
HDMI 1.3V CABLE
Product Details:
Conductor: Tinned Copper
Jacket: UL PVC
Color: Black (May according to request to match colors)
SPECIFICATION: (1P*30AWG+D+AL+Mylar)*4C+1P*30AWG+5C*30AWG+AL+D+B OD: 6.0mm
Rating: TEMP 80C: VOLTAGE 30V
Standard Type: HDMI 1.3V Cable
PHYSICAL PROPERTIES OF JACKET:
1. Tensile Strength: Unaged: 1500PSI min Aged: 70% min
2. Elongation: Unaged: 100% min Aged: 65%
3. Heat shock test: NO CRACKING
4. Cold bend test: NO CRACKING
5. Deformation test: MAX 50%
6. Flame test: PASS VW-1
ELECTRICAL CHARACTERISTICS
1. Rating: TEMP 80C: VOLTAGE 30V
2. Conductor Resistance: AT 20C MAX 30AWG: 376.96Ω /km;
3. Insulation Resistance: 10MΩ -km min at 20C DC 500V
4. Dielectric Strength: AC 500V/1minute no breakdown.
5. Fext< -20dB
6. Impedance: 100± 10Ω
7. Attenuation:
(1) 0.3~825MHz < 5dB/ 3M; (2) 0.825~2.475GHz < 5~12 dB/3M; (3) 2.475~4.125GHz < 12~20 dB/2.5M
(4) 4.125~5.1 GHz < 20~25 dB/2.5M
8. Time Delay Skew: Within a pair less than 111ps/ cable;
Between pairs: Less than 1.78ns / cable
*These data are limited to raw cable.
Marking: High Speed HDMITM Cable E325852 AWM Style 20276 80C 30V VW-1
RoHS compliance available, UL certification
Additional Info:
Packing: 100m/coil-200m/coil
Origin: HuiZhou GuangDong
MOQ: 5km
Capacity: 1000km /Month
