| Prod Model: |
YPF1 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| New Design: |
9000-15000BTU |
| Function: |
Cooling, Heating, Dehumidify, Fan |
| Color: |
White and Grey |
| Ypf1-09c: |
9000BTU/2600W |
| Type: |
Portable Air Conditioner |
| Usage: |
Room |
| Indoor Machine Noise: |
>50dB |
| Certification: |
BEB |
| China Energy Efficiency Standard: |
Level 1 |
| Cooling/Heating: |
Cooling/Heating |
| Power Source: |
Electrical |
| Power Type: |
DC |
| Condition: |
New |
| Capacity: |
9000BTU-13000BTU |
Product Description
Construction Features1. Self-evaporation, new generation. Water generated inside is reused, no need to empty water,power saves.
2. Water disposed by a spraying motor.The machine works perfectly in wet area with high EER.
3. Rectangular shape looks handsome and silver-printed housing appears luxury.
4. Reversible LCD, indicating temperature and operation status.
5. Anti-frozen function under cooling.
6. Self-diagnosis function and 24 hour On/Off timer.
Other Features and Functions1.louvers swing automatically,wind auto-swings.
2.soft touch control panel
3.high quantity.
Color
front white back grey
Loading Quantity20"/40"GP/40"HQ: 128/266/397
|
| European Market | North American Market |
| Model | Unit | YPF1-09C | YPF1-12C | YPF1-09C | YPF1-12C |
| Cooling capacity | Btu/h | 9000 | 12000 | 9000 | 12000 |
| W | 2600 | 3500 | 2600 | 3500 |
| Heating capacity | Btu/h | N/A | N/A | N/A | N/A |
| W | N/A | N/A | N/A | N/A |
| Power Supply | V~,Hz,Ph | 220~240,50,1 | 220~240,50,1 | 110~120,60 | 110~120,60 |
| Rated input | Cooling | W | 1020 | 1400 | 1000 | 1250 |
| Rated Current | Cooling | A | 4.5 | 6 | 8.7 | 11 |
| Rated input | Heating | W | N/A | N/A | N/A | N/A |
| Rated Current | Heating | A | N/A | N/A | N/A | N/A |
| EER for Cooling(R410A) | Btu/W.h | 9 | 8.3 | N/A | N/A |
| W/W | 2.62 | 2.45 | N/A | N/A |
| COP for Heating(R410A) | Btu/W.h | N/A | N/A | N/A | N/A |
| W/W | N/A | N/A | N/A | N/A |
| Moisture Removal | L/h | 0.8 | 1.2 | 0.8 | 1.2 |
| Air Circulation | m³/h | 400 | 420 | 400 | 420 |
| Noise | High | dB(A) | 55 | 55 | 55 | 55 |
| Middle | dB(A) | 53 | 53 | 53 | 53 |
| Body Size | W×H×D | mm | 443×830×340 | 443×830×340 | 443×830×340 | 443×830×340 |
| Package Size | W×H×D | mm | 480×885×430 | 480×885×430 | 480×885×430 | 480×885×430 |
| Net Weight/Gross Weiht | kg | 25/30 | 28/33 | 25/30 | 28/33 |
| Appliation Area | m2 | 10~15 | 18~25 | 10~15 | 18~25 |
| Loading Quantity | Set/40"HQ | 385 | 385 | 385 | 385 |
| Set/40"GP | 258 | 258 | 258 | 258 |
| Set/20" | 126 | 126 | 126 | 126 |
| Remarks: : 1.The above technical data are for reference only. Yoau reserves the right to modify them without notice |
| 2. If you want to use the above data for artwork of carton, user manual etc, please ask Yoau for confirmation. |
Changzhou Fengrun Import and Export Co., Ltd. is a professional manufacturer of evaporator & condenser for air-conditioner and refrigerator; Steel tube and other cooling system products.
Currently Fengrun has 22 production lines for evaporator & condenser of air-conditioner, the annual production cpacity is able to reach 4 million PCS, which is the largest production base in China. Under this condition, Fengrun also owns a rollbond workshop with annual capacity 3.5 million PCS, a wire on tube condenser workshop with annual capacity 2.5 million PCS, a wire on tube evaporator workshop with annual capacity 2.0 million PCS, a no-frost(fin type) evaporator workshop with annual capacity 1.0 million PCS.
Otherwise, Fengrun owns a workshop which produces steel tube 30 thousand ton per year and also has sone equipments which can produce copper products such as three-way, three-claw, elbows 3 million PCS and Cu-AL connecting tubes 600 thousand PCS per month.
