Prod Model: |
FIF |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Usage: |
for Refrigerate |
Cooling Method: |
Direct Cooling |
Compressor: |
Bitzer/Bock/Copeland |
Gas: |
R22/R404A |
Ice Shape: |
Flake Ice |
Certification: |
CCC |
Product Description
Focusun FIM Series Flake ice machine
With Daily capacities from 1Ton/day up to 60Ton/day, well tuned system can handle most of the working conditions on the earth, reliable component and cheap cost to run, what else are you waiting for?
Product features:
1. High degree of Customization
All of Focusun flake ice machines are build to order, we can design machine suit to any working conditions or we can make only upon your requirements.
Below are the options available for you: -
Power supply: XxV/xxHz/3P
Refrigerant type: R404A/ R22
Cooling way: AirCool/ WaterCool/ EvaporativeCool
Material of Evaporater: Chromoplated Carbon Steel/ SS403 StainlessSteel
Compressor: Bitzer Screw/ Piston
Containerized/ Non-Containerized
Ect...
Focusun brand flake ice maker models:
Model | Daily Capacity | Refrigerant | Electricity consumption | Operating weight | Size (L×W×H) |
FIF-05 | 0.5T | R404A | 2.5kw | 530kg | 1100×700×630mm |
FIF-08 | 0.8T | R404A | 3.67kw | 560kg | 1200×740×650mm |
FIF-10 | 1T | R404A | 4.3kw | 620kg | 1200×740×800mm |
FIF-20 | 2T | R404A | 7.15kw | 680kg | 1560×1200×960mm |
FIF-30 | 3T | R404A | 11.3kw | 720kg | 1700×900×1200mm |
FIF-40 | 4T | R404A | 14.94kw | 780kg | 1700×900×1201mm |
FIF-50 | 5T | R404A | 17.28kw | 860kg | 2200×1050×1550mm |
FIF-60 | 6T | R404A | 21.24kw | 950kg | 2200×1050×1606mm |
Model | Daily Capacity | Refrigerant | Electricity consumption | Operating weight | Size (L×W×H) |
FIF-50WB | 5T | R404A | 21.8kw | 1120kg | 2200×1050×1550mm |
FIF-60WB | 6T | R404A | 22kw | 1600kg | 2150×1350×1580mm |
FIF-80WB | 8T | R404A | 26kw | 1800kg | 2450×1650×1600mm |
FIF-100WB | 10 | R404A | 34.3kw | 3000kg | 3550×1550×2100mm |
FIF-150WB | 15T | R404A | 49.35kw | 3400kg | 4000×1850×2400mm |
FIF-200WB | 20T | R404A | 68.4kw | 3600kg | 4200×2000×2914mm |
Model | Daily Capacity | Refrigerant | Electricity consumption | Operating weight | Size (L×W×H) |
20ft | FIF-50C | 5T | R404A | 17.72kw | 3600kg | 6058×2438×2591mm |
FIF-100C | 10T | R404A | 34.31kw | 4700kg | 6058×2438×2591mm |
FIF-120C | 12T | R404A | 38.8kw | 5500kg | 6058×2438×2591mm |
FIF-150C | 15T | R404A | 49.35kw | 5500kg | 6058×2438×2591mm |
FIF-200C | 20T | R404A | 60.41kw | 6100kg | 6058×2438×2591mm |
40ft | FIF-250C | 25T | R404A | 78.85kw | 6500kg | 12192×2438×2895mm |
FIF-300C | 30T | R404A | 102.45kw | 6800kg | 12192×2438×2895mm |
FIF-400C | 40T | R404A | 147.35kw | 8000kg | 12192×2438×2895mm |
FIF-500C | 50T | R404A | 176.3kw | 8500kg | 12192×2438×2895mm |
FIF-600C | 60T | R404A | 204.9kw | 9200g | 12192×2438×2895mm |
2. Reliable components
Simens, Schnider, Bitzer, Danfoss, EBM...etc we only choose the world renowned brand for our components supplier, by doing this will enable your machine running perfectly on balance for 20 Years.
Condensor and Evaporater are made by the National Certified Manufacturer, each of them came out with one unique Identity plate, it is the commitment to the quality and your satisfaction.
3. Compact design and easy operate
FIM200K has adopt all the latest computer technology in manufacturing and operating. All datas and input prarameters are processed by the Siemens PLC; We use sensor instead of guage, wiring of piping. This is how we upgrade the quality, and this is what enables you a easy and safe operating.
4. Efficient
By utilizing the Most Efficient compressor Bitzer, and the most reasonable design of pipe line, our flake ice machine are rated the lowest power and water consumption ice machines now days.
Payment terms
50% T. T. Down payment, 50% T. T. Before shipping
Lead time
38 working days after the reciept of down payment
Warranty
Full- one year
Focusun Refrigeration is the most professional manufacturer in China, specialized in designing and manufacturing of high quality ice making machines, such as: Flake ice machine, cube ice machine, tube ice machine, and block ice machine. We have earned the position of dependable supplier among a vast global clientele due to consistency in quality of our product range and services offered to the clients.
As a well established manufacturer and exporter, we lay special attention to our manufacturing process and delivery of products: Flake ice machine, cube ice machine, tube ice machine, and block ice machine. We take utmost care of quality at every stage of the manufacturing process. Our staff of highly qualified engineers combines the benefits of irreplaceable practical experience with the sophisticated accuracy of our own interactive graphics computer system enable us to provide high quality product, prompt deliveries, dependable service, and outstanding customer satisfaction.
Focusun is known across the country for our premium quality on the products we offer. We have a hi-tech production unit that uses the latest technology and the most modernized machinery. We have a strong and proficient workforce, comprising of technically skilled professionals and efficient workers. Our research and development wing is our asset that develops and incorporates innovative ideas and products.
Our products: Flake ice machine, cube ice machine, tube ice machine, and block ice machine are globally known for their dimensional accuracy, high efficiency & durability and they are used in various fields such as aquatic food processing, supermarkets, healthcare centers, man-made skiing resort, mines, large-scale concrete construction, etc. The product model ranges from small-sized ice machines with a daily output of 230kgs to large-sized sets of ice making system up to 60tons in 24hours and 85% of our ice making machine's components are imported and all undergo rigorous monitoring and quality control system to ensure superb quality of our flake ice machine, cube ice machine, tube ice machine, and block ice machine.
We pride ourselves on quality, service and pricing, and believe that all three areas are equally important to ensure the long-term success of your overseas purchasing program. Our sustained relationship with customers serves as testimonial for our high quality products. The fusion of superior quality and reasonable prices make our products capable of influencing anyone in the whole world. Our reputation in the market is synonymous with high quality, updated technology and dedicated approach.
