| Prod Model: |
FIB block ice making machine |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Compressor: |
Bitzer/Bock/Copeland |
| Gas: |
R22/R404A |
| Condenser: |
Air Cooled/Water Cooled/Evaporative Cooled |
| Quality: |
High Quality Block Ice Making Machine |
| Certification: |
CE |
| Ice Shape: |
Ice Block |
| Condition: |
New |
Product Description
Block ice application:
1. Fisheries and aquatic food processing;
2. Vegetables distribution and fresh-keeping;
3. Supermarket/hotel fresh keeping;
4. Edible ice, etc.;
Non-containerized Brine refrigeration block ice making machine features:
1. Ti pipe is used as evaporative coil to improve heat transfer effect and prevent rust, corrosion for longer life.
2. The part inside brine tank that touches brine water is made of PE/SS304 which bears low temperature and highly resists rusts.
3. Particular can dump and thawing tank design makes easier operation.
4. Thaw tank is heated by air discharge from compressor to save much energy and suits for low water temperature area.
5. Every brine block ice machine can be designed and built as per your specific requirements.
Our Non-containerized brine refrigeration block ice maker models:
| Model | Daily
Capacity | Refrigerant | Electricity
consumption | Install
power | Operating
weight | Size (L×W×H) |
| FIB-50B | 5T | R22/R404A | 20.9kw | 25kw | (unit):960kg | L1400×W1000×H1250mm |
| (evaporator):2860kg | L4800×W1000×H2250mm |
| (cooling tower):460kg | 1380×H2170mm |
| FIB-100B | 10T | R22/R404A | 33.98kw | 50kw | (unit):1680kg | L1800×W1000×H1450mm |
| (evaporator):2860kg×2(p.c.) | L4800×W1000×H2250mm |
| (cooling tower):670 | 2000×H2410mm |
| FIB-150B | 15T | R22/R404A | 59.15kw | 75kw | (unit):2160 | L2000×W1200×H1600mm |
| (evaporator):2860×3 | L4800×W1000×H2250mm |
| (cooling tower):1120 | 2175×H2565mm |
| FIB-200B | 20T | R22/R404A | 85.55kw | 105kw | (unit):2896 | L2400×W1600×H1800mm |
| (evaporator):2860×4(p.c.) | L4800×W1000×H2250mm |
| (cooling tower):1300 | 2650×H2645mm |
| FIB-250B | 25T | R22/R404A | 94.05kw | 120kw | (unit):3260 | L3200×W1800×H2200mm |
| (evaporator):2860×5(p.c.) | L4800×W1000×H2250mm |
| (cooling tower):1630 | 3050×H2780mm |
| FIB-300B | 30T | R22/R404A | 113.55kw | 150kw | (unit):3500 | L3000×W2000×H2200mm |
| (evaporator):2860×6(p.c.) | L4800×W1000×H2250mm |
| (cooling tower):2730 | 3300×H2785mm |
Containerized brine refrigeration block ice machine features:
1. Convenient transportation and installation, no need to build a room for the container and machine.
2. Self-contained condensing unit is pre-piped and wired.
3. New ISO container equipped with lighting and drainage system.
4. Economically saving on cost and operation, advanced free maintenance design requires no specially trained engineer.
Our containerized brine refrigeration block ice making machine models:
| Model | Daily Capacity | Refrigerant | Electricity
Consumption | Operating
Weight | Size |
| 20foot container | FIB-10BC | 1T | R22/R404A | 6.0kw | 960kg | 6058×2438×2591mm |
| FIB-30BC | 3T | R22/R404A | 14.0kw | 2180kg | 6058×2438×2591mm |
| FIB-50BC | 5T | R22/R404A | 20.9kw | 3820kg | 6058×2438×2591mm |
| 40 foot container | FIB-80BC | 8T | R22/R404A | 30.79kw | 5600kg | 12192×2438×2895mm |
| FIB-100BC | 10T | R22/R404A | 33.98kw | 7400kg | 12192×2438×2895mm |
Tell us your needs (as specific as possible), like wanted daily capacity, ice usage, block ice weight or popular ice size in local market or desired ice making time, suitable suggestions provided or can be also specially customized.
PS: Standard block ice maker is designed on 33ºC dry ball temp. and 25ºC water temp. (If temp. different, please inform us when enquiry, can be customized. If your local temp. very very high, above 45ºC, don't worry, just let us know, we'll provide you right solution);
Focusun Refrigeration is the most professional manufacturer in China, specialized in designing and manufacturing of high quality ice making machines, such as: Flake ice machine, cube ice machine, tube ice machine, and block ice machine. We have earned the position of dependable supplier among a vast global clientele due to consistency in quality of our product range and services offered to the clients.
As a well established manufacturer and exporter, we lay special attention to our manufacturing process and delivery of products: Flake ice machine, cube ice machine, tube ice machine, and block ice machine. We take utmost care of quality at every stage of the manufacturing process. Our staff of highly qualified engineers combines the benefits of irreplaceable practical experience with the sophisticated accuracy of our own interactive graphics computer system enable us to provide high quality product, prompt deliveries, dependable service, and outstanding customer satisfaction.
Focusun is known across the country for our premium quality on the products we offer. We have a hi-tech production unit that uses the latest technology and the most modernized machinery. We have a strong and proficient workforce, comprising of technically skilled professionals and efficient workers. Our research and development wing is our asset that develops and incorporates innovative ideas and products.
Our products: Flake ice machine, cube ice machine, tube ice machine, and block ice machine are globally known for their dimensional accuracy, high efficiency & durability and they are used in various fields such as aquatic food processing, supermarkets, healthcare centers, man-made skiing resort, mines, large-scale concrete construction, etc. The product model ranges from small-sized ice machines with a daily output of 230kgs to large-sized sets of ice making system up to 60tons in 24hours and 85% of our ice making machine's components are imported and all undergo rigorous monitoring and quality control system to ensure superb quality of our flake ice machine, cube ice machine, tube ice machine, and block ice machine.
We pride ourselves on quality, service and pricing, and believe that all three areas are equally important to ensure the long-term success of your overseas purchasing program. Our sustained relationship with customers serves as testimonial for our high quality products. The fusion of superior quality and reasonable prices make our products capable of influencing anyone in the whole world. Our reputation in the market is synonymous with high quality, updated technology and dedicated approach.
