Flight Aviation Headset with Passive Noise Attenuation

Flight Aviation Headset with Passive Noise Attenuation
Price: US $ 25-40/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 100/Piece
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: headset
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Usage: Telephone, Workstation, Server, Helicopter
Support Network: Ethernet
Information Content: Voice
Certification: GS, Ce, RoHS, ISO
Condition: New
Style: Headband
Line-Control: Line-Control
Microphone: With Microphone
Function: Monitoring
Use: Industrial
Earpad Size: One Size
Color: Black
Wire Material: TPE
Type: Wired

Product Description












1,   Adjust the headband to make it fit you.
2,   Wear the headset, and adjust the headband again, also adjust the earpad position till you feel the noise reduction function is the best.
3,   Move the microphone 5-10mm distance from your lip.
4,   Insert the microphone (5.23mm) and speaker (6.35mm) plug to the corresponding jack.
5,   Turn on the equipment for this headset.





Attention:
1,  It's important to wear the headset well, as that will directly affect the noise reduction effect.
2,  Maintenance and Cleaness
Do not tear apart it by yourself.If you found something unnormal, please stop to use it.
Please keep the headset clean by wiping it with soapy water.
3,Do not dip it into water.
4,Do not clean it by chemical.


















Specifications

Noise Reduction Ratings(NRR):24dB
Headphone
Type:Dynamic 40)
 Frequency Response: 100Hz to 8KHz
Sensitivity:95±5 dB SPL    (1 kHz, 1 mW input per earcup side)
full volume on ear simulator
Impedance:   150 ohms/mono,300 ohms/stereo
Rate Input:10mW
Max. Iuput: 100mW
Microphone and Amplifier
Element Type:   Electret Noise-canceling
Frequency Response:   100Hz to 8kHz
Operating Voltage:    8-32 Volts DC
Matching Impedance:    150-2200 ohms
Sensitivity: -28±4 dB
General
Temperature:
Operating: - 20 to 70°C
Cordage:
Straight cord from headset to molded plug, 150CM
Intercom Connections:
Earphone Plug:   Φ6.3 phone plug
Microphone Plug:  Φ5.2 phone plug
Weights: 470g

Headset size range
Height: 10 to 14 cm
Color: Black
Boom:Flexible Boom


WE ALSO MAKE AND SUPPLY THE AVIATION HEADSETS, WITH HIGH QUALITY PROFESSIONALLY, WHICH SELL TO AMERICA, details pls contact us RIGHT NOW.
