| Prod Model: |
FD2510 |
| Size: |
25mm*25mm*10mm |
| Bearing: |
Ball Bearing |
Product Description
| Model | Bearing Type | Rated Voltage | operation Voltage | Current | Speed | Air Flow | Pressure | Noise | Weight |
| VDC | VDC | A | RPM | CFM | mmH2O | dBA | g |
| FD2510B2H-**** | Sleeve/ Ball | 12 | 10.8~13.2 | 0.13 | 13000 | 2.85 | 7.76 | 30.26 | 6 |
| FD2510B2M-**** | 0.1 | 10000 | 1.85 | 4.43 | 25.06 |
| FD2510B2L-**** | 0.06 | 7000 | 1.52 | 4.18 | 19.47 |
| FD2510B1H-**** | Sleeve/ Ball | 5 | 4.5~5.5 | 0.23 | 13000 | 2.85 | 7.76 | 30.26 |
| FD2510B1M-**** | 0.18 | 10000 | 1.85 | 4.43 | 25.06 |
| FD2510B1L-**** | 0.13 | 7000 | 1.52 | 4.18 | 19.47 |
Brushless DC Motor | Bearing Type | Function Options | Plug Type |
Housing : PBT 94V0 | 2-Ball | Frequency Generator | Auto Restart | 1.00 |
Impeller : PBT 94V0 | Sleeve | Temperature Control | Rotation Detection | 1.25 |
Impedance protected | Hydraulic | PWM Control | | 1.50 |
Lead wire:UL 1061 AWG 28# | 1-Ball-1-Sleeve | | | 2.00 |
* All fans are with electronic protection against reverse polarity. The fan only operates when the polarity is correct.
