| Prod Model: |
YL Mobile Precison Oil Purifier |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Function: |
Mobile Precison Oil Purifier |
| Color: |
Grey or as Customer Request |
| After-Sales Service Provided: |
Engineers Available to Service Machinery Overseas |
| Electric Wiring: |
IEC Standard |
| Delivery Time: |
30-40 Days |
| Voltage: |
as Customers Need |
| Folw Rate: |
as Customers Need |
Product Description
Simple to operate and convenient for maintenance. Features low cost and high filtration precision, it is the updating product of the plate frame pressure oil purifier.
Mobile Precison Oil Purifier Feature:
Explosion Proof Mobile Precison Oil Purifier is suitable to filter various impurities in insulating oil, turbine oil, mechanical oil, hydraulic oil 1-5 or more multi-stage filtration acceptable, filters can be wash / clean to reuse.
Filters choice diversified according to your oil and usage.
Mobile Precison Oil Purifier is replacement for the frame-pressurized oil filling machine. It is simple in structure and easy to operate with low price.
For high-quality oil recondition machine as vacuum oil filling machine, please search our ZJA, ZJB, JZ, ZJC, JT, DYJC, KYJ We have full series from low to high for your choice.
Mobile Precison Oil Purifier Parameters
Parameter |
Type
Unit |
YL-50 |
YL-80 |
YL-100 |
YL-150 |
YL-200 |
Flow Rate |
L/min |
50 |
80 |
100 |
150 |
200 |
Motor Power |
KW |
1.1 |
1.5 |
2.2 |
3 |
4.4 |
Inlet/Outlet Diameter |
mm |
32/25 |
38/32 |
44/38 |
48/44 |
64/48 |
Weight |
Kg |
100 |
120 |
150 |
200 |
260 |
Working Pressure |
Mpa |
≤0.5Mpa |
Power Supply |
|
50Hz380V 3-Phase 4-Wire (or as requested) |
Filtering accuracy |
µm |
≤5 |
Delivery lift |
m |
≥15 |
Yuneng products list:
1. Insulation Oil filling machine:
ZJA Ultra-high Transformer / Insulation Oil filling machine (1000KV, ±800KV, 750KV, ±660KV project) ( 2 stage vacuum)
ZJA High-vacuum Transformer / Insulation Oil filling machine (110KV-500KV project)) (2 stage vacuum)
ZJB Transformer / Insulation Oil filling machine (≤110KV) (one stage vacuum)
ZJ Filter Filtration Fine Oil Purifier (extract vacuum, dry transformer)
GF Dry Air Generator (produce dry air for operators to maintain transformer, reactors).
JZ OLTC (on-load tap changer) online Oil filling machine
Quantitative oil injection machine (customized product)
2. Turbine Oil filling machine:
JT coalescing dehydration oil filling machine (dehydration by special filters)
DYJC online turbine oil filling machine (dehydration by special filters and vacuum system)
ZJC-T vacuum oil filling machine for turbine oil (dehydration by vacuum system)
3. Lubricating Oil filling machine:
ZJC-R vacuum Oil filling machine for lubricating oil (machinery oil, hydraulic oil, compressor oil, coolant oil, cutting oil..)
ZJC-M Oil filling machine for OCS. (oil with high viscosity 22-320cst at 40°C)
4. Other kinds of oil filling machine:
KYJ fire-resistance oil filling machine (EHC oil)
LY plate-frame pressure oil filling machine (simple, paper filtration)
YL SMobile Precison Oil Purifier (simple, cheap)
5. Waste oil regeneration machine (by chemicals or by high temperature distillation)
YNZSY used oil filling machine (by chemicals)
YNZSY-LTY used tire oil filling machine (by chemicals)
Waste oil distillation machine
6. Oil tester/ analyzer:
Dielectric oil breakdown strength tester
Water content tester
Inline Digital Flow Meter and Totalizer
Viscosity analyzer
Flash point analyzer (close cup)
Flash point analyzer (open cup)
Interfacial tension analyzer
Gas chromatograph
Chongqing Yuneng Oil-Filter Manufacturing Co., Ltd. is a new and high-tech joint-stock enterprise established on the basis of the former Chongqing Yuneng Oil-Purifier Factory. Our company, covering an area of about 14, 500 square meters, specializes in the R&D, manufacture, and marketing of oil, water and gas filtering and purification products and complete sets of related equipment. We gather a group of specialized talents with years of working experience and technological development. Now we have 228 employees, and 60% of them have received an educational background at or above the junior college level. We can produce 1, 000 sets of oil-filtering equipment and purification equipment for other fluids every year. We are one of the world competitive companies specializing in high-tech oil purifier research and manufacture.
We attach great importance to product quality, specialization, dedication and constant improvement. Aiming to become a world-advanced manufacturer of oil treatment equipment, we have always upheld the development philosophy centering on "technological innovation and service improvement". We have passed ISO quality management certification. Besides, ten of our new technologies have received national patents of invention and five of our oil purifier series have been granted the title of "new and high-tech products of Chongqing". In 2004, our company was rated as a new and high-tech enterprise of Chongqing. In addition, with the support and help of the Chongqing Commission of Science and Technology, our company implemented EPR information management system in 2006. All these lay a solid foundation for our company to provide customers with high-quality reliable products and fast and comprehensive service to avoid homogenous competition on quality improvement.
Over the past 20 years, we have always stuck to the operational concept of "being faithful and dedicated, practical in development, and cooperative for common progress". By working in a down-to-earth manner and orientating ourselves to customer needs, we have received the recognition of a lot of customers. So far we have sold over 15, 000 sets of Yuneng-brand oil purifiers, which are widely used in electric, metallurgical, petrochemical, mechanical, military industry, railway, light industry, and other industries. Our products enjoy a fairly big market share and have become a famous brand in medium- and high-grade oil treatment equipment.
According to the long-term development objective of the Group, we set up a new company called Chongqing Xingao Electromechanical (Group) Co., Ltd. The new Group will continue to seek innovation and dedicate itself to the research and manufacture of high-end oil treatment technologies. It will also seek diversified development to cover the manufacture of water and gas purification equipment and filtering consumables as well as the assembly of electro-mechanical and environmental protection equipment, so as to realize the goal of making strong main business while making the company bigger as a whole. We are ready to do our part to develop national industries, save energy and protect the environment.
We are looking forward to cooperating with you.
