| Prod Model: |
DTA4.2 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Price: |
Please Contact Us for Prices. |
| Height: |
2 U |
| Output Pwoer: |
400W at 8 Ohm |
| OEM Production: |
Acceptable |
| Application: |
Commercial |
| Certification: |
CB |
Product Description
Switching Mode Power Supply (SMPS) Power Amplifier DTA4.2
SPECIFICATIONS
| Model No. | DTA4.2 |
| Output power at 8 ohm stereo 1kHz(HIA) with0.5% THD (per channel) | 400Wx2 |
| Output power at 4 ohm stereo 1kHz(HIA) with0.5% THD (per channel) | 750Wx2 |
| Output power at 8 ohm 1kHz(HIA)with0.5% THD 8ohm bridge mono | 1800W |
| Voltage Gain | 32.8dB |
| Frequency Response(at 1 Watt) | 20Hz-20kHz,+0/-1dB |
| Total Harmonic Distortion(THD) | <0.5%,20Hz-20kHz |
| Intermodulation Distortion(1MD) 60Hz and 7kHz at 4:1,from full rated output to -30dB | ≤0.35% |
| Slew Rate | >10V/us |
| Damping Factor(8 ohm),10Hz-400Hz | >200 |
| Signal-to-Noise Ratio (below rated power,20Hz to 20kHz,A-weighted) | >100dB |
| Crosstalk (below rated power) | |
| At 1 kHz | -75dB |
| At 20 kHz | -59dB |
| Input 5ensitivity for full rated power at 8 ohm | 0.775V or 1.4V |
| Input Impedance(nominal) | |
| Balanced | 10K ohm |
| Unbalanced | 20K ohm |
| Protection features | Protection against short circuits, no-load, on/off muting, Rf interference.5table into reactive or mismatched loads |
| Dimensions (WxHxD) | 483x88x320 mm |
| Net weight | 7.8Kg |
PRODUCT FEATURES
This DTA Series adopt full bridge (SMPS) switching mode power supply with high efficiency and stability, third grade CLASS-H audio amplifier circuit. Both 2 and 4 channel are available. The main features are as the following:
. Patented and elegant enclosure design. The aluminium front panel brings you the sense of high quality. Very light in weight and easy to install.
.Well-crafted machine with compact structure.
.Strong output power and applicable to a variety of applications.
. Integrated circuit ensuring excellent and independent output for the multi-region sound reinforcement system.
.Advanced and full protection circuit against short-circuit, broken circuit, direct current, error matching, over-heat and no-load.
.Well selected and strong material of inside components and the enclosure. Good anti-vibration.
.Long-lasting performance stability
.Good cooling system with automatic speed fan with high efficiency of heat dissipation.
.Accurat, and clean sound quality with very low distortion.
. Speakon® socket, binding post output connector, XLR input connector and speaker parallel connector.
.Well tested by AP testing machine to ensure strong stability. Product packing:
