Double-Stage Vacuum Insulation Oil Purifier
| Price: |
US $ 13000-15000/Set |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Set |
| Pay Type: |
L/C,T/T |
| Prod Model: |
ZYD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Ultimate Vacuum: |
<5PA |
| Continuous Working Time: |
>300h |
| Working Noise: |
<65dB |
| Working Pressure: |
<0.3MPa |
| Working Vacuum: |
<133PA |
| Breakdown Voltage: |
>70kv |
| Structure: |
Mobile |
| Type: |
Suction Filter |
| Mechanical Principle: |
Vacuum |
Product Description
ZYD-II Double-Stage Vacuum Insulation Oil Purifier can quickly remove water, trace water, gas, particles as well as acetylene, hydrogen, methane and other harmful ingredients from oil effectively to improve oil's dielectric strength, effectively making sure electric equipments working safely and normally. Series ZYD-II oil purifier is particularly suitable for treating high-grade transformer oil, super-voltage transformer oil and new transformer oil. It can be used for filtration of more than 110V substation live line work onsite. Meanwhile, Series ZYD-II oil purifier can be used as independent vacuum source with functions of vacuum drying and vacuum oiling. | Features: |
|
| 1. Double-stage vacuum system, strong power of vacuum evacuating, ultimate vacuum value ≤ 5Pa |
| 2. Two vacuum separating chambers, efficient oil film sprayer, increasing separating size and separating time to ensure the dry-level and dielectric strength improving greatly. |
| 3. Duplex-Stereo film evaporation technology, combined with unique and advanced dewatering, degassing components, can rapidly and effectively separate water, gas from oil. |
| 4. Multi-stage precision filtration system, mesh filtration combined with molecular adsorption technologies |
| 5. Efficient electric heating system, heating uniformity, less power consumption, safe, and reliable. |
| 6. Double-infrared liquid level sensor, pressure protective system to ensure machine operation easy and safely. |
| 7. Adopt interlocked protective system, which connect oil pump, heater and liquid level sensor, avoiding blank heating, blank pumping, oil leak and electricity leak. If there is any fault, machine will be power off automatically. |
ZYD-II Technical Parameters | Index name | ZYD-II | 30 | 50 | 80 | 100 | 125 | 150 | 200 | 250 | 300 |
| Flow rate | L/min | 30 | 50 | 80 | 100 | 125 | 150 | 200 | 250 | 300 |
| Ultimate vacuum | Pa | ≤5 |
| Working vacuum | pa | ≤133 |
| breakdown voltage | kv | >70 |
| Working pressure | Mpa | ≤0.3 |
| Working Temperature | C | 30-80 |
| Power supply |
| 380V 50HZ 3Ph (According to customers' power supply) |
| Continuous working time | H | ≥200 |
| Working noise | dB | ≤65 |
| Heating power | KW | 24 | 30 | 48 | 60 | 72 | 90 | 120 | 150 | 180 |
| Total power | KW | 28.5 | 34.5 | 53 | 68 | 80 | 99 | 132 | 165 | 198 |
Series ZYM Mobile type transformer oil purifierThe mobile type oil purification machine is equipped with mobile trailer and enclosed doors. It is mainly for outdoor operations, the structure is suitable for ZYD, ZYS, ZYT, ZTL, ZTC, ZYV oil filtration machine, it is often used for ZYD and ZYS for treating unqualified transformer oil switch oil, mutual inductor oil etc. Besides all functions of series ZYD, ZYS, the best advantage of ZYM is that can move long distance working in field.The ZYM oil purification machine features:| I. Reasonable designed, enclosed type, water-proof, dust-proof, easy to move. |
| II. To install car tires, Bridge shock absorber; braking system; all steel firm structure trailers, thus, these ensure the speed 60km/h. |
| III. For ZYD, ZYS machine, it can treat the unqualified transformer oil, insulating oil very effectively; for ZYT, ZYL, ZYC it can remove water, gas, particles etc. from lubricating oil, cooking oil. |
| IV. New type of efficient electric heating system, heating uniformity, less power consumption. |
| V. Be equipped interlocked protecting system, oil discharge system, vacuum system, interlocked heating system, to make sure the machine run smoothly. |
| VI. For ZYM-10, ZYM-20,ZYM-30,ZYM-50: two wheels, dead load: more than 300kg |
For ZYM-100, ZYM-150, ZYM-200, ZYM-300: four wheels, dead load: more than 500kg
