Double 10 Inch Compactive Line Array (CA-0010)
| Price: |
US $ 100.55-350.55/Piece |
| Trade Terms: |
FOB,EXW |
| Min Order: |
2/Piece |
| Pay Type: |
T/T |
| Prod Model: |
CA-0010 |
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| The Size Of Woofer: |
2 X 10" High Power Woofer |
| The Size Of Tweeterr: |
1 X1.75" High Fidelity Compression Driver Unit |
| Components: |
2X10"+1.75" |
| Type: |
Dual 10" 2-Way Line Array |
| Material: |
Plywood Cabinet |
| Noise: |
<102dB |
| Hi-Fi: |
Hi-Fi |
| Operation Mode: |
Wire / Remote Control |
| Speaker Material: |
Wood |
| Application: |
Commercial |
| Certification: |
CE |
| THD: |
<0.005% |
| Activity: |
Passive and Active |
| Speaker System: |
Professional Performance |
Product Description
NOVA professional for line array, pro audio, professional loudspeaker, amplifier, flight case and driver units.
Our CA2812 line array are high power loudspeaker. With high performance, wide bandwith specification, they are suit in highest level of connect touring, stadium, large club, stage, theater and auditorium etc.| Model Number | CA2812 | CA-2212 | CA-0010 | CA008 | CA110 |
| Frequency Response | 45HZ-20KHz (-10dB) | 55HZ-19KHz (-10dB) | 120Hz-20KHz (-10dB) | 120Hz~20 KHz (3dB) | 100Hz~20 KHz (3dB) |
| 50Hz-19KHz ( ±3.5dB) | 50Hz-18KHz ( ±3.5dB) | 130Hz-19KHz (±3.5dB) |
|
|
| RMS power | HF: 100W, MF: 220W, LF:800W | HF: 150W, LF:800W | HF:80W, LF:600W | 350W | 300W |
| Program power | HF: 200W, MF: 440W, LF:1600W | HF:300W, LF:1600W | HF:160W, LF:1200W | 700W | 600W |
| Peak power | HF: 300W, MF: 660W, LF:2400W | HF:450W, LF2400W | HF:300W, LF1800W | 1050W | 900W |
| Norminal Impedance | HF:4Ohm, MF:16Ohm ,LF:4Ohm | HF:8Ohm, LF:4Ohm | HF:8Ohm, LF:4Ohm | 16Ohm | 8Ohm |
| Sensitivity | 108dB/w/m | 105dB/w/m | 101dB/W/M | 101dB/M/W | 123dB/M/W |
| Max SPL | 136DdB | 134Db | 120dB | 126B | 126B |
| Component | 2x12"+2X8"+2X2" | 2x12"+3" | 10" x2 +2" | 8" x2 +2" | 10" +2" |
| Coverage Angle | 90° H X10°V | 90° H X10°V | 90°H X10°V | 100°H X7°V | 60°H X10°V |
| Dimension | (370x265) x 1175 x 610mm | (370x270) x 920 x 570mm | (300x230)x800x445mm | (245x190)x640x335mm | (300x245)X520X350mm |
CA0010 Specification:
Frequency response: 120Hz----19KHz (-10dB)
130Hz----18KHz (+/-3.5dB)
RMS power: HF: 80W/ LF: 800W
Norninal impedance: HF: 8Ohm/ LF: 4Ohm
Sensitivity: 101dB/W/M
Component: 2x12" +3" horn
Dispersion angle: 90H degree X 10V degreeSpeakers, speaker system, audio speaker, sound speaker, stereo speaker, pro audio speaker, pro audio loudspeaker, pa loudspeaker, pa speaker, pa system, audio system, sound system, line array, line array system, line array speaker, loudspeaker China, line array China.NOVA introduce the CA series compact line array system for large and medium sound reinforcement applications, Desighed for use in theaters, houses of worship and performing arts centers, the systems profides audio professionls with a lightweight, thigh output array that offers exceptional audiuo fidelit.
PASSIVE AND ACTIVE AVAILABLE.
No built-in amplfiier and built-in amplifier.| CA0010 Specification |
|
| Frequency response | 120Hz-20KHz (-10dB) |
| 130Hz-19KHz (±3.5dB) |
| RMS power | HF:80W, LF:600W |
| Program power | HF:160W, LF:1200W |
| Peak power | HF:300W, LF1800W |
| Norminal impedance | HF:8Ohm, LF:4Ohm |
| Sensitivity | 101dB/W/M |
| Max SPL | 120dB |
| Component | 12" x2 +2" |
| Coverage Angle | 90°H X10°V |
| Dimension | (300x230)x800x445 |
Nova specializes in manufacturing PRO audio which including line array, professional loudspeakers & KTV, power amplifiers, mixers consoles, signal processors including equalizers, limiters/compressors, exciters, crossovers, power sequence controllers etc. To meet different customer's market, we also add producion line for woofer speakers, subwoofer speakers and flightcase for sound equipmentand professional lights and LED monitor ect.
With experienced & strong R&D department and strictly quality control managment and Satisfactory market service system and reasonable price and good quality, Our price had got high reputation in many ares.
OEM/ODM also available.
Nova will offer what you want.
Please join in NOVA family!
