| Prod Model: |
P8 |
| Brightness: |
High Brightness, HD |
| Factory: |
OEM, ODM |
| Cabinet Material: |
Waterproof Cabinets |
| Warranty: |
2 Years |
| Tube Chip Color: |
Full Color |
| IP Rating: |
IP65 |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Video Display |
| Average Power Consumption: |
300W / m² |
| Scanning Mode: |
1/4 Scan |
| Display Type: |
LED Video Display |
| Certification: |
CCC |
| Pixel Pitch: |
8mm |
| Pixel Density: |
15625 Dots/M2 |
| Application: |
All, Concerts, Shows and Event, Airport |
Product Description
Features:
1. There are rubber mask and rubber top cover that ensures on damage can be exerted by any external impacts.2. We are using Epistar 346/546 LED lamps with good level of brightness.3. A patented soft mask over the surface of the screen being installed to ensure no vivid impact damages of any kind can be seen.4. We use Nuetrik power Connector and Meanwell power supply.5. We utilize a louver based heat sink to increase the radiation potentials of the system in an overall sense.6. We utilize a simple, yet high strength mechanical framework as the core for the whole installation.7. Our solution integrates and encompasses hanging and leasing purpose screens with the soccer field itself into one.8. We have instituted an interlocking device between modules, easy to manage and install.9. Each cabinet is equipped with a high strength metallic module for ease of moving and lifting.10. The cabinet has embarked on a unique triangular design that even if the cabinet itself is in a physical tilting position, its door can be opened with ease.Contact Us Now to know more: mobile: +86 13538127671
Items | Parameter | |
| Product Model | P8 Full Color Led Module | |
| Module size | 256mm*128mm | |
| Pixel pitch | 8mm | |
| Pixel density | 15625dots/m2 | |
| Pixel configuration | RGB 3 in 1 | |
| Module resolution | 32dots(W)*16dots(H) | |
| Module maximum power consumption | 25W | |
| Module Thickness | 2.8CM | |
| Module Weight | 0.6kg | |
| Driving method | Constant Current Driving | |
| Scanning method | 1/4 scan | |
| Interface | HUB75B | |
| Brightness | ≥7500cd/m2 | |
| The specifications of cabinets | |
| |
| Cabinet size | 768mm x 768mm | |
| Module quantity | 18pcs | |
| Power supply | 5V/40A 5V/60A | |
| Cabinet resolution | 96*96dots | |
| Optimal viewing distance | 8M ~ 80M | |
| Optimal viewing angle | 160°(W) 120°(H) | |
| RH Working temperature | (Work :-20 °C~ +50 °C ) | |
| System operating humility | 10%-95% | |
| The specifications of power supplier | |
| |
| Operating Voltage | AC220V±10% | |
| Average power consumption | 300W/H | |
| Maximum power consumption | ≤600W/square meter | |
| Electric current | ≤20mA(single LED) | |
| The specifications of control card | |
| Control Panels | Pentium4 or above | |
| Operating system | WIN98/2000/NT/XP | |
| Control model | Synchronization with PC | |
| The specifications of the main technical parameters | |
| |
| Driving device | Constant Current Driving | |
| Refresh rate | ≥600HZ | |
| Grey scale | RGB Each 256, can display 16.7M colors) | |
| MTBF | ≥9000hours | |
| Power switch | Automatic Switch | |
| Display Mode | 800*600/1024*768/1280*900
|
Why Chengxinguang(CXG) LED Display
1. Competitive Price
We are middle-sized Chinese local factory, maybe you can see that from our so Chinese name of "Chengxinguang", unlike the internationalized name of foreign trade company. Besides, we control our cost very well and don't have huge management cost like top companies, so that we can give the real benefits to our customers.
2. Close Relationships with Raw Material Providers
For our bosses have been in the key positions at the top led display factory since 2004, we have very close and strategic relationship with the raw material providers, which support the stable quality of our products.
3. Quality Control
From raw materials to finished product, from design to produce, we control all steps, which are the guarantee of the quality and reliability.
Chengxinguang Technology Co., Ltd (Brand: ACE LED) is located in Shenzhen, China, a major production base of global LED display screen industry. Chengxinguang is a professional LED display screen manufacturer. It provides professional and customized solutions on full color LED display screen, rental LED display, outdoor electronic LED signs, indoor LED displays, LED curtain display, moving message boards, variable message sign and video boards etc.
Chengxinguang is committed to our customers and partners by providing fast and genuine service, quality and value. Now we have established business relationship with customers in Asia, America and European countries etc, and we will continue to devote ourselves to providing customers with excellent performance products, efficient and effective services around the world.
Chengxinguang uses international high-end automated production equipment and has professional management, R&D, production, quality and service teams. Besides, we also have very strong and strategic relationship with the raw material providers. All of these factors have ensured the stability and quality in our LED products, and our competitive price.
Contact us today and learn why so many customers world-wide choose Chengxinguang as their partner for LED displays.
