| Prod Model: |
E20 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Burner: |
Air Heater Burner |
| Usage: |
Indirect Air Heating,Drying ,Food Processing |
| Principle: |
Mixing Heat Exchanger |
| Structure Material: |
Metal Material |
| Application: |
Heater |
| Heat Transfer Surface: |
Plate Heat Exchanger |
Product Description
The E Series Air Heat Burners
SUNSRAYS' "E Series Air Heat Burners" are line type burners ideal for generating volume of clean, hot air. Applications include oven, dryers, fume incinerators, and similar industrial equipment. AirHeat provides simple, reliable operation, plus lower CO emissions than other competitive air heating burners.
All models feature an integral combustion air blower mounted on the burner's steel case. By supplying the correct air volume and pressure to the burner, the blower allows stable operation over a wide range of duct velocities without installing a profile plate around the burner. The burner can also be ordered without a blower for use in recirculating air applications.
Ready for the world
AirHeat burners combine advanced engineering with installation and operational features that are truly world class.
Can be direct spark ignited.
Does not require low-fire bypass air, eliminating the need for piping and check valve.
Simplified set-up with pressure taps for gas, air and chamber.
Inputs up to 1.0MM BTU/hr/LF.
Operate on any commercially available gas_natural gas, propane, butane and propane/butane mixture.
Aluminum castings eliminate need for special corrosion-resistant manifolds.
Burner mounting arrangements include duct mounting, slot firing and sealed flange mounting with insertion depths up to 6".
| Type | Number of Sizes | Capacity Range | Turndown |
| Nozzle Mixing | Modular | 1, 000, 000 (BTU/hr/LF) | 40: 1 |
Max. Process Temperature: 1500° F, 815° C
Fuels: Natural Gas, Propane
Typical Applications:
Incinerators
Dry-off nnd curing ovens
Indirect air heating
Textile Drying
Food Processing/baking
Ceramic Drying
Key Attributes:
Lowest CO emissions. Compact modular design. Robust, reliable performance. Industry Standard.
