| Prod Model: |
FJ4ED-450. FG. V |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Condition: |
Brand New |
| Bearing: |
Ball Bearing |
| Product Type: |
Double Voltage Industrial Cooling Fan |
| Size: |
450mm |
| Warantee: |
One Year Guarantee Time |
| Type: |
Ventilation Fan |
| Speed: |
1 Speed |
| Power Supply: |
Electric |
| Power: |
100W-300W |
| Application: |
Industrial |
| Timer: |
Without Timer |
Product Description
Overview
Motor
Cage type capacitor start external rotor motor
Impeller
Pressed from metal armor plate, impellers are welded to motor rotor and its surface is black and anti-corrosion
Fixed Guard
Steel wire is finished with black paint and anti-corrosion treatment
Allowable environment temperature and
humidity range:(under unconcretionary condition)
-30°C -+75°C (temperature) 0% ~ 95% (humidity)
Protection
Automatic recovery thermal protection
Withstand Voltage
AC 1,800V , 1 min at 0.5mA, 50/60 Hz
Insulation Grade
Design according to IEC61858 Grade F
Protection Grade
IP44
Specifications |
Category | Axial fan |
| Type | FJ4E-450.FGV |
| Rated Voltage | 230V |
Frequency | 50/60Hz |
Current | 1.12A-1.50A |
Input Power | 245W-340W |
Speed | 1350RPM-1480RPM |
Max Air Flow | 3250-3560CFM |
Static Pressure | 105Pa-75Pa |
Noise | 68dB-71dB |
| Capacitor | 8.0/450 |
Weight | 7.2KG |
