| Prod Model: |
FIM-600K |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Daily Capcity: |
60000 Kg |
| Water Consumption Type: |
Seawater, Brine Water |
| Certification: |
CCC |
| Ice Shape: |
Flake Ice |
| Condition: |
New |
Product Description
Focusun 60T/24H Marine Seawater flake ice plant:
Focusun Sea water flake ice makers are divided into four major categories, including small capacity flake ice machine (daily production ranging from 500 kg -2, 500 kg), medium capacity flake ice machine (daily production ranging from 3, 000 kg - 20, 000 kg), large capacity flake ice machine (daily production ranging from 25, 000, -60, 000) and containerized flake ice making plants (two models: 20-foot standard container and 40-foot standard container).
Configuration: The design meets with the standard of the classification society. The use of one or more Bitzer (oil) semi-hermetic piston compressor accords with sea water cooling and sea water condenser. All parts are welded together. So it is strong enough to run normally even in a pitching and rolling ship.
Features: Designed for navigation system operation, it overcome the seawater corrosion and the ship's pitch
The advantages of flake ice as follows:
Irregular ice flakes with size about 40× 40mm and thickness around 1.5-2.5mm.
The thin ice can be directly used for stirring and mixing refrigerated materials;
No acute edges and corners so it will not damage the surface of the cooled object;
Large contact area and fast cooling speed;
Easy to crush and mold.
1. Cost-saving
There is no need for construction of workshop so it saves the initial investment, labor cost and time a lot.
Besides, the whole system is completely installed in the container, fully automatic so that very minor labor is needed for both operation and installation.
2. Easy installation
Pre-assembled and well-tested ice plants installed in 20ft or 40ft containers are ready for connection to water and electricity. No complicated on-site installation work is needed at all. Once filled with refrigerant, the machine can start immediately after being connected to water and electricity.
3. Movable
Focusun containerized ice plant is easily transportable by truck or rail, making it particularly useful in remote locations, or those that need to move ice making facilities from one project site to another.
4. Convenient transportation
The cargo container is suitable for ocean container shipping and it saves the operation of packing into or taking out the ice machine from the container. Thus it prevents the ice plant from getting damaged during the long-distance transportation.
5. High-quality cargo container
The flake ice machine is installed into ISO certified standard ocean freight container. With decent modification to reinforce the structure, the container is ready to handle heavy machines in operating, lifting and transporting. PVC coated cargo container makes sure the ice machine inside is sheltered form the wind and rain.
6. Stable operating environment
The container provides a relatively closed operating environment and maintains the appropriate inside temperature. It ensures the stable and efficient ice making process.
7. Compact & Space-saving
All equipments are installed in the container compactly, making the most of the internal space of the container. Compared with installing the non-containerized ice making machine on the workshop, the containerized ice maker saves much space. It only takes about 13.2m2(20ft container) and 26.4m2(40ft container) totally.
Please contact us if you are interested in our Sea Water FLAKE ice machine, we can supply from 0.5ton/day to 60ton/day. And we provide perfect turnkey solution.
Turnkey Solution
As the most professional ice making plant supplier in China, Focusun can systematically provide customers with a series of comprehensive ice-making solutions. Once you have the idea of building an ice-making project, if necessary, our experienced engineers will provide you with professional projects proposals.
| Subject | Unit | Technical parameter |
|---|
| Power supply | Voltage/Phase/Frequency | 380V/3P/50Hz |
| Refrigerant |
| R22 or R404A |
| Capacity | Kg/day | 60000 |
| Cooling way |
| Water cooling |
| Temperature | Ambient temperature | Celsius deg | 35 |
| Waterinlet temperature | Celsius deg | 20 |
| Compressor | Manufacturer |
| GRASSO |
| Refrigeration capacity | Kw | 350 |
| Total running power | Kw | 195 |
| Compressor COP/EER | Kw/kw | 1.8 |
| Horse power | Hp | 350×1set |
| Operating power | Total running power | Kw | 214.9 |
| Installment power | Kw | 280 |
| Operating power of reducer | Kw | 3.7 |
| Operating power of cold water pump | Kw | 1.5 |
| Cooling water pump | Kw | 11 |
| Fan of cooling tower | Kw | 3.7 |
| Diemnsion | Size of ice maker | (L×W×H)(mm) | Unit:3400×2200×2200 |
| Evaporator:3000×2500×4500 |
| Size of cooling tower | (O.D.×H)(mm) | Φ3770×3490 |
| Size of water feeding pipes of cooling tower |
| 1" |
| Size of cooling water pipes |
| 6" |
| Size of water feeding pipe |
| 1" |
| Size of ice outlet | mm | Φ2160 |
| Weight of unit | Operating weight of flake ice maker | Kg | Unit:4500 |
| Evaporator:6500 |
| Operating weight of cooling tower | Kg | 3640 |
| Water supply pressure requirement | Bar | 1.5
|
