| Prod Model: |
YB12832D |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Display Format: |
128*32dots |
| Outline Dimension: |
110*65*14.5mm |
| Visual Area: |
76.0*25.0mm |
| Active Area: |
72.92*18.19mm |
| Diagonal Size: |
3.15 Inch |
| IC Or Equivalent: |
Ks0107/S6b0107/Sbn6400 or Eqv |
| Interface: |
6800 8-Bitparallel |
| Display Type: |
Stn/FSTN |
| Appearance: |
White on Blue/Black on Yellow Green/White on Gray |
| Power Supply(Typ): |
3.3V/5V |
| Usage: |
Small-sized LCM |
| Digital LCD Module Type: |
Counting Module |
| Touch Screen Type: |
Resistive |
| Type: |
LCM |
| Response Time: |
1ms |
| Display Technology: |
STN |
| DOT-Matrix Graphic LCD Module Type: |
Row/Column-Driven Control Type |
| LCD Drive Mode: |
Multiplex Drive LCD Module |
| Customized: |
Customized |
| Viewing Angle: |
6.0 |
Product Description
1.The product description
| Gross Weight (kg) |
|
| Manufacturer | YaBin |
| Series Number | YB12832D |
| Display Format | 128*32Dots |
| Outline Dimension | 110*65*14.5mm |
| Visual Area | 76.0*25.0mm |
| Active Area | 72.92*18.19mm |
| Diagonal Size | 3.15 inch |
| Dot (Pixel) Size | 0.52*0.52mm |
| Dot (Pixel) Pitch | 0.57*0.57mm |
| IC Package | COB |
| IC or Equivalent | KS0107/S6B0107/SBN6400 or EQV |
| Interface | 6800 8-bitParallel |
| Display Type | STN/FSTN |
| Sunlight Readable | No |
| Touch Panel Optional | No |
| Contrast Ratio(Typ) | No |
| Viewing Direction | 6:00 |
| LED Backlight Color | Blue /Yellow Green /Gray |
| Appearance | White on Blue/Black on Yellow Green/White on Gray |
| Power Supply(Typ) | 3.3V/5V |
| Backlight Current (Typ) | 45mA |
| Operating Temp | -20ºC~70ºC |
| Storage Temperature | -30ºC~80ºC |
| If accept customized | Yes |
| RoHS Compliance | Yes |
2.cost of description
| 1.Material cost breakdown |
| Product model | YB12832-D | specifications | yellow-green/blue 5V
(standard configuration) |
| Items | price(USD) | Items | price (USD) |
| Print circuit board | 0.59 | electronic element | 0.65 |
| Liquid Crystal Display | 1.23 | Integrate circuit (IC) | 1.07 |
| Iron box | 0.2 | Chip on board assembly
(independent production) | 0.5 |
LED backlight
(independent production) | 0.48 | production cost
(SMT+COB+assembly+packing) | 0.5 |
| Conductive article | 0.04 | material loss | 0.2 |
| cost of total amount | 5.46 |
| 2.Market pricing |
| Minimum quantity (PCS) | Rate of profit(%) | total profit (USD) | Ex price (USD) |
| 1-49(sample) | 35% | 1.91 | 7.37 |
| 50-99(Small batch) | 30% | 1.64 | 7.10 |
| 100-499(Small batch) | 25% | 1.37 | 6.83 |
| 500-999(big batch) | 20% | 1.09 | 6.55 |
| More than 1,000(big batch) | 15% | 0.82 | 6.28 |
If there is disagreement on the above price please contact me with details, thank you!
|
3.Other graphic products is introduced
| All kinds of graphic liquid crystal display |
Series
Number | inch | Display
Format | Outline
Dimension | Active
Area | mounting
dimension | Point
size | Driver
IC | voltage /V |
| 3.3 | 5 |
| 12232-A | 2.4 | 122x32 | 84x44 | 60x18 | 79x36 | 0.35x0.4 | SED1520 |
| √ |
| 12232-B | 2.4 | 122x32 | 84x44 | 60x18 | 79.1x36 | 0.35x0.4 | SED1520 |
| √ |
| 12832-A | 3.1 | 128x32 | 110x65 | 76x25 | 105x61 | 0.52x0.52 | KS0108 | √ | √ |
| 12832-D | 3.1 | 128*32 | 110x65 | 76x25 | 105x61 | 0.52x0.52 | KS0108 | √ | √ |
| 12864-A | 3.27 | 128x64 | 113x65 | 73.4x38.8 | 105x57 | 0.48x0.48 | KS0108 | √ | √ |
| 12864-D | 3.1 | 128x64 | 93x70 | 70X38.8 | 88x65 | 0.48x0.48 | KS0108 | √ | √ |
| 12864-G | 4.2 | 128x64 | 107x85 | 88x60 | 100x78 | 0.6x0.8 | KS0108 | √ | √ |
| 12864-I | 2 | 128x64 | 54x50 | 43.5x29 | 49x45 | 0.28x0.35 | KS0108 | √ | √ |
| 12864-J | 2.7 | 128x64 | 75x54.7 | 60x32.6 | 70x49.7 | 0.4x0.4 | KS0108 | √ | √ |
| 12864-L | 3 | 128x64 | 78x70 | 62X44 | 68x65 | 0.39X0.55 | KS0108 | √ | √ |
| 16080-D | 5.6 | 160x80 | 152.5x72.5 | 128x64 |
| 7.1x6.8 | KS0086 | √ | √ |
| 19264-A | 4.4 | 192x64 | 130x65 | 104x39 | 121x53 | 0.458x0.458 | KS0108B | √ | √ |
| 19264-B | 3.5 | 192x64 | 100X60 | 84x31 | 93x55 | 0.37x0.37 | KS0108B | √ | √ |
| 19264-E | 4.4 | 192x64 | 122x62 | 115x57 | 115x57 | 0.458x0.458 | KS0108B | √ | √ |
| 160128-C | 5.1 | 160x128 | 129x102 | 101x82 | 122x96 | 0.54x0.54 | RA6963 | √ | √ |
| 24064-B | 5.4 | 240x64 | 180x65 | 132x39 | 176x54 | 0.49x0.49 | RA6963 | √ | √ |
| 240128-A | 5.1 | 240x128 | 144x104 | 114x64 | 138x97 | 0.4x0.4 | RA6963 | √ | √ |
| 240128-B | 5.1 | 240x128 | 144x104 | 114x64 | 138x97 | 0.4x0.4 | RA6963 | √ | √ |
| 320240-A | 5.7 | 320x240 | 160x109 | 122x92 | 152.3x104.7 | 0.33x0.33 | RA8835 | √ | √ |
| 320240-B | 5.7 | 320x240 | 160x109 | 122x92 | 152.3x104.7 | 0.33x0.33 | RA8835 | √ | √ |
| 320240-D | 5.1 | 320x240 | 139x100 | 103x79 | 131x97.5 | 0.27x0.27 | RA8835 | √ | √ |
4.Packaging
1).Cartons, Cupboard, EPE, Blister Tray.
2).About how many products in one package, it is up to the size of products.
3).according to customer request.
5.My service
| 1.Assure our product quality |
| 2. Produce high quality products. |
| 3.Produce RoHS compliant products. |
| 4.Meet customer special demands |
| 5.Semi- or fully-custom design products |
| 6.Provide professional service |
| 7.Stable and long-term supply |
| 8.Timely response |
| 9.Small demand support |
6.FQA
| 1.Q: Are you manufactory or trade company? |
| A:We are professional manufactory, which specializes in TN, HTN, FSTN, STN ,TFT ,OLED Color LCD display module and monochrome liquid crystal display module ,LCD modules more than 10 years in Shenzhen! Our advanced full set equipments make sure good quality and competitive price! |
| 2.Q: How can I get the samples? |
| A: Send inquiry → Offer quotation →Confirm quotation & pay tooling charge → Provide drawing → confirm drawing → make tooling & samples → Samples finished → Delivery via freight collect |
| 3.Q: How long can I expect to get the sample? |
| A:Contour drawing: 2-3 days Sample time: 10-15 business days |
| 4. Q: what kind of check can provide? |
| A: shenzhen yabin electronics have multiple test by different departments,from material procurement to finished product QA, QC, salesrep resentatives,ensure all franchise player is in good condition before shipment. We also accept the inspection you designated third party. |
| 5.Q: Can you design the lcd in accordance with our demand? |
| A:Sure.We will give you the best tooling charge. |
| 6.Q:How to place orders ? |
| A:If you confirm samples ok, Please send us your purchase order by Email or Fax , Then we will send you an Invoice for deposit payment. We need to know the following information of your order. |
| 1)Product information-Quantity,part number |
| 2)Delivery time required. |
| 3)Shipping information-Company name, Street address,Phone&Fax number,Destination sea port. |
| 4)Forwarder's contact details if you have any in China. |
| 7.Q:How long of mass production ? |
| A: 25-30 business days. It depends on different order quantities and part number. |
