| Prod Model: |
Clear P10 16/20/8mm LED Module Panel Display |
| Name: |
Clear P10 16/20/8mm LED Module Panel Display |
| Chip Color: |
Red Color 1r LED Display |
| Cabinet: |
According to Customers Request |
| Dots: |
10000 Dots/Sq |
| Customized: |
Yes OEM ODM as Your Request |
| Available: |
P10 P8 P6 P4 P2.5 P16 P20 P7.62mm Ect |
| Used For: |
Outdoor and Indoor |
| Emitting Colorv: |
Super Bright Red Green Blue |
| Modle No.: |
Rx Red Green Blue Color Outdoor LED Display Screen |
| Brand: |
Rx Outdoor LED Display |
| Tube Chip Color: |
Dual-color |
| IP Rating: |
IP65 |
| Pixel Pitch: |
10mm |
| Pixel Configuration: |
1R, 1G, 1B |
| Display Function: |
Video Display |
| Average Power Consumption: |
350W / m² |
| Pixel Density: |
10000 dot / m² |
| Scanning Mode: |
1/4 Scan |
| Display Type: |
LED Video Display |
| Application: |
Advertising |
| Certification: |
SGS |
Product Description
Clear P10 16/20/8mm LED Module Panel Display
| Pixel pitch | 10mm |
| Module size | 160*160mm |
| Module density | 10,000dots/sqm |
| Module resolution | 16*16 |
| Pixel configuration | 1R1G1B |
| Red wavelength | Epistar taiwan 625±2nm |
| Green wavelength | Epistar taiwan 525±2nm |
| Blue wavelength | Epistar taiwan 470±2nm |
| Best viewing distance | From 10 to 150 |
| Horizontal viewing angle | 110° |
| Vertical viewing angle | 90° |
| Maximum power consumption | Below 800W |
| Brightness | 7500cd/sqm |
| Gray scale | More than 4096 |
| Control method | Synchronization |
| Driving method | 4Sconstant current |
| Frame frequency | 60Hz |
| Refresh frequency | More than 300 Hz |
| Working voltage | AC220V±5% |
| IP grade | IP65 |
| Working temperature | -20°C±50°C |
| MTBF | More than 5,000 hours |
| Life span | More than 100,000hours |
| Cabinet style | Waterproof cabinet |
| Cabinet size | W640*H640*D120mm |
| Cabinet weight | Less than 28kgs |
| Application | |
| Full color | Outdoor media, industrial park, road traffic, bank, hospital and community. |
| |
Advertising media, sports stadiums, airport station integrated information dissemination, business establishments, public square |
| Product Features: | |
| 1 | Ultrahigh definition display effect, 0.1mm high-precisio splice seam |
| 2 | New structure design, meet the Hanging wall mounted assembly requirements, and meet indoor outdoor requirements |
| 3 | With ultra high refresh rate, to ensure clear picture |
| 4 | Fast and convenient assembly and dismount system |
