| Prod Model: |
IL-NP |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Application: |
Domestic Hot Water |
| Vaccum Tube Size: |
47*1500mm,47*1800mm,58*1800mm |
| Color: |
Different Colors for Choosing |
| Using Life: |
15 Years |
| Quality Warranty: |
5 Years |
| Collector Components: |
Glass Vacuum Tube |
| Pressure: |
Unpressurized |
| Structure: |
Compact Type |
| Interior Material: |
Stainless Steel |
| Certification: |
CCC |
| Max. Capacity: |
350L |
| Composition: |
Water Tank, Vacuum Tubes, Bracket |
Product Description
Vacuum Tube Non Pressure Solar Water Heater manufacturer Haining Yinuo Electric Co., ltd,
About us:
We manufacture all kinds of solar water heaters, exporting to more than 40 countries with good quality and price, OEM is offered free to customize your own brand, with 20 years experience in solar field, we are ready to offer our best products and service to you.
Contact us freely if there are things we can do for you.
Simple description about this type of Vacuum tube non pressur solar water heater:
Non pressure solar water heater is such a most economical system with high efficiency at the same time. It works depending on the gravity of water, so it's much better to be installed on the slope or flat roof as top as possible to get enough hydraulic pressure for shower. A simple assistant tank can be equipped for tap water refill automatically or with an intelligent controller to control the auxiliary heating device and water refill at the same time.
Details:
Vacuum tube: Hail-resisting 3.3 borosilicate glass with high-tech single-target selective coating ensures an efficient solar collecting, tri-target vacuum tube with its patent interference coating makes the efficiency not only improved by 12% but also with a 380oC high temperature resistantce without peeling off the coating layer.
Inner water tank: Food-grade stainless steel SUS304-2B as inner tank keeps the water clean and drinkable, together with advanced argon arc welding technics to ensure it with a long lifespan (more than 15 years).
Water tank shell: Imported color steel plate, with its special coating treatment ensures a long life even to ocean coast weather.
Insulation Layer: High-density polyurethane integrated foam-forming with twice slaking treatment, preserves hot water temperature as long as 70~80 hours.
Supporting Bracket: Very strong hot-DIP galvanized steel plate with a good weight bearing and wind resistance design (140 km/hr), painting or baking process ensures a super mechanical performance and corrosion resistance, easy installation, universal bracket suitable for either flat and slope roof installation.
Accessories: Stainless bolts & nuts, water-proof silicon rubber, anti-aging dustproof rubber seal, plastic pipe holder and ventilating cap to ensure their lives as long as other parts of the system
Optional Devices
Assistant tank, automatically feed tap water into storage tank to keep it sufficient always
Electrical heater, as an auxiliary heating element in case of raining or cloudy days so as to ensure a continous hot water supply
Intelligent controller, automatically controls water refill and startup of auxiliary heating device, more intelligent system operation
Warranty: 5 years international responsibility for integrated system exchange and 15 years for glass vacuum tube compensation due to original quality problems
|
Vacuum tube |
Spec. (mm) |
Φ 47× 1500 Φ 47x1800 Φ 58× 1800 Φ 70× 2000 |
|
Tube (pcs) |
15 / 16 / 18 / 20 / 22/ 24 / 28 / 30 |
|
Material |
3.3 Borosilicate glass, magnetron spluttering selective coating |
|
Coating |
AL/AL-ALN(H)/AL-ALN(L)/ALN or Cu/SS-ALN(H)/SS-ALN(L)/ALN |
|
Water tank |
Capacity |
70 ~ 400L for inner water tank |
|
Inner tank |
Food-grade stainless steel plate SUS304-2B |
|
Insulation |
High-density polyurethane integrated foam-forming 50~60mm |
|
Tank shell |
Color steel plate |
|
Bracket |
Spec. (mm) |
1.2 ~ 1.5mm thickness |
|
Material |
Hot-dip galvanized steel plate |
|
Accessories |
Stainless bolts & nuts, Silicon rubber seal, Dustproof rubber seal, Plastic pipe holder |
|
Optional device |
Electrical heater, Intelligent controller / Assistant tank, Anod magnesium bar |
|
Tilt angle |
25° ~ 50° |
|
Water output |
45-95 o C |
|
Hail resistance |
Φ 25mm diameter |
Since 1995 Haining Yinuo Electric Co., Ltd has dedicated itself to saving global resources by supplying the world with superior solar water heating systems.
Haining Yinuo Electric Company is situated in the beautiful village of Haining 100 km to the port of Shanghai and covers a production area of 12, 000 square meters. It produces 48, 000 solar water heaters and 27, 00 high capacity industrial solar water heating systems per year, 60% of which are exported to overseas markets.
Haining Yinuo Electric Co. Is equipped with state of the art manufacturing equipment imported from Germany and carefully trained technicians. Its products are certified by ISO and CE and have a quality reputation throughout Germany, France, America, South Korea, South Africa and the world. Haining Yinuo Electric Company's is well known as a supplier of well designed and affordable products, and its competent and professional staff.
Haining Yinuo Electric Company's mission is to serve its customers by providing them with the most appropriate solutions to their individual requirements. Regardless of your particular circumstances, Haining Yinuo Electric Company's friendly, professional and experienced staff will tailor a special solution to your needs that will surprise and delight you.
You are welcome to surf around our website, compare our products, and ask us questions, we are just a click away from you.
