| Prod Model: |
FT-C |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Simen Motor: |
Stain Steel |
| Certification: |
CCC |
| Electric Current Type: |
AC |
| Mounting: |
Ceiling Fan |
| Blade Material: |
Stainless Steel |
Product Description
1..Fan blade is made of Krupp stainless steel by punch forming,Thickness 1.2mm, surface finish BA grade.no dust,attractive and durable.The special blade keep the large air volume,no deformation,no broken,Keep the air volume same all the way.
2.Both Chinese famous motor and Siemens motor are available.The motor voltage and frequency could be customized.Chinese famous car special fan,the first one put forward the phase lack protection device which could power off when shortage of electricity.Motor protection grade is IP55,insulation class:Grade F.
3.The fan belt pulley is made of high strength aluminum-magnesium alloy by die-casting which can reduce the weight of fan blade and high corrosion resistance.
4.The fan bearing adopts imported double-row bearing with special waterproof design,water can not enter.High strength,low noise,maintenance free and long service life.
5.The centrifugal system could open the shutters at complete 90 degree to ensure the lowest air resistance and biggest air volume.when closed,the sealing can efficiently block light and wind into the poultry farm house.As the first one adopts high quality nylon 100% to ensure the long service life.The fasteners of centrifugal system all are copper rivets,wear-resisting and no dust,flexible.Guide rod is made of 304 stainless steel,ensuring the high strength,no dust,reduces frication.
6.Technical parameter:
Model sepcifications Diamter blades(mm)Frequency
(hz)Motor rotational speed rpmAir flow (m3/h)Import power(w)Rated voltage(v)Nosie decibelsHeight(mm)Width(mm)Thickness(mm)
FT-910910(36min)50≥140035000750380≤6410001000450
FT-12701270(50min)50≥1400480001100380≤6413801380450
FT-14001400(56min)50≥1400558001500380≤6415301380450
