| Prod Model: |
DG-I13-75 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
CCTV Camera |
| Sensor: |
CCD |
| Style: |
Bullet Camera |
| Feature: |
Waterproof / Weatherproof |
| Technology: |
Infrared |
| Kind: |
Manual Focus Lens |
| Horizontal Resolution: |
560tvl |
Product Description
Features:
1/3" SONY CCD High resolution 560/600TV Line
42pcs 5 LED for excellent night view
Vari-focal lens 2.8-12mm
Cable management bracket
OSD/Auto Gain Control/HLC
Dual power optional
IP 66
DC12V/AC24V
|
Specicications |
|
|
|
|
|
Model |
DG-I13-75H-12 |
DG-I13-75S-12M |
|
Image Sensor |
1/3" SONY CCD |
|
Signal System |
PAL/NTSC |
|
Horizontal Resolution |
560TVL |
600TVL |
|
Effective Pixels |
PAL: 752(H)x582(V) |
PAL: 976(H)× 582(V) |
|
NTSC: 768(H)x494(V) |
NTSC: 976(H)× 494(V) |
|
Scanning System |
Interlace |
|
IR LED |
42pcs |
|
IR Distance |
35-40m |
|
Lens |
2.8-12mm |
|
Scanning Frequency |
PAL: 15.625KHz(H), 50.00Hz(V) |
|
NTSC: 15.734KHz(H), 59.94Hz(V) |
|
Sync System |
Internal |
|
Min. Illumination |
0.01Lux/F1.2 |
0.0003 LUX/F1.2 |
|
White Balance |
Manual/ATW/AWC/Push |
|
Backlight Compensation |
On/Off |
Auto |
|
Motion Detection |
On/Off |
On/Off(4 areas) |
|
D/N Switch |
Auto/Color/B& W/EXT |
|
Wide BLC |
--- |
100dB |
|
Privacy Masking |
Manual |
|
Picture Adjust |
Peripheral Brightness Compensation/Mirror |
Peripheral Brightness Compensation(0-6) |
|
Function |
2DNR/D-WDR On(0-60)/Off |
ConnectorRJ485/Communication Protocol PELCO-D/ |
|
Baud Rate 2400/4800/9600/14400/19200 |
|
Sens-up |
--- |
Off/x2/x4/x8/x16/x32/x64/x128/x256/x512 |
|
Electronic Shutter |
PAL: 1/50-1/100, 000sec |
|
NTSC: 1/60-1/100, 000sec |
|
Video Output |
1.0Vp-p/75Ω Video |
|
Gamma |
0.45 |
|
Language |
Chinese/English |
|
S/N Ratio |
> 48dB |
|
Input Voltage |
DC12V± 10% |
|
Operating Temperature |
-10C-+60C |
|
Storage Temperature |
-20C-+60C |
|
Operating Humidity |
≤ 90% |
|
Dimension |
291.3*83*81 |
|
Weight |
1203 |
