| Prod Model: |
CA127 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
Black |
| Power Input: |
DC 18V~36V |
| Power Output: |
DC 12V |
| Maximum Active Power: |
45W X 4 |
| Delivery Period: |
in One Weeks After Payment Received |
| Output Power: |
100 - 200W |
| Ripple Voltage: |
Less 100mv |
| Noise Ratio: |
≥80db |
| Power Consumption: |
180W |
| Input Sensitivity: |
200mv |
| Type: |
Car Radio |
| Placement: |
Dashboard |
| Voltage: |
12/24V |
| Audio Output: |
Digital Audio Coaxial |
Product Description
Quick Details
1) color: black
2) SNR: 75 - 90dB
3) Frequency Range (Hz): 20Hz~20KHz
4) Voltage: DC24V or 12V
5) Impedance: >60dB
Feature
Build amplifier function
Three-way6.35 standard MIC input
Highly reliable modular design
Bulit-in professional digital effect module
Specification
| Item | Specification |
| Power Input | DC 18V~36V |
| Power Output | DC 12V |
| Output Current | ≤10A |
| Ripple voltage | Less 100mV |
| No-load Current | Less 60mA |
| Reverberation Time | 2.3s(adjustable) |
| Frequency | 20Hz~20KHz |
| Noise Ratio | ≥80dB |
| THD | ≤0.03% |
| Channel Separation | >60dB |
| Impedance | 100K |
| Maximum Active Power | 45W x 4 |
| Input Sensitivity | 200mv |
| Power consumption | 180W |
| Net Weight | 1.5KG |
Our company information :
Founded in 2007 ,Xiamen Harine Electronics Co.,Ltd has become a professional designer and manufacturer of vehicular electronics products . Harine has passed the ISO9001- 2008 quality system certification and product certification and has been assessed as a national Hi-tech enterprise which specialized in design , production and sales of vehicular LCD&LED monitor , vehicular audio& video system, rear view system and so on .
With advantage of long-period experience in vehicular products, powerful R&D team, good team sense and efficient and effective production, Harine selles the products to all over the world and has been approved to be the first choice in the field.
Presently, our factory covers an area of 3.000 square meters, has about 200 employees and 50 million RMB turnover in 2012.
We firmly believe that quality comes the first. Most of our products has been CE, FCC, Certificated or E-mark approved.
