| Prod Model: |
XLQ-XT |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Unit Capacity: |
15-900t/H |
| Micron: |
20-500um |
| Control Way: |
Differential Pressure, Time and Manual |
| Back Wash Time: |
50-90s |
| Differential Pressure In Cleaning: |
0.01-0.08MPa |
| Usage: |
Chemical Industry |
| Motive Force: |
Electric power |
| Certification: |
SGS, ISO |
Product Description
Best Commercial Automatic Self Cleaning Screen Water Filter
How It Works
The unit consists of two stages of filtration, a coarse pre-filter and
a stainless steel fine screen.The unwanted solids accumulate on the inner surface of the fine screen, building up a filtercake,which filters out even finer particles, creating a pressure differential. Once the pressuredropreaches a preset level,a rinse cycle is activated by the factory supplied control system.
The solids are removed from the fine screen using a spot backwashing method, whichaggressivelysucks the dirt off the screen, similar to a vacuum cleaner, and are carried tothe drain via the rinsenvalve. The dirt collector rotates, ensuring the entire screen is cleanedeach cycle. The process takesa matter of seconds, without interruption of system flow.
Control method
Filter has differential switch and integrator. Once the pressure drop reaches a preset level, a rinse cycle is activated by the PLC controller.
Feature
Structure compact
Low water consumption
Fine filter degree
Low pressure drop
Application
1,Chilling water treating: such like cooling tower, water supplement system, air conditioningsystem, heat exchange system.
2,Raw water treating: such like surface water, lake, sea water, tank water, well to removegrind, sand, algae, organism etc.
3,Cycling industry water: cooling tower, polishing process water, ion exchange water, sprayingprocess water, heat exchange plant, rolling plant, casting plant etc.
4,Irrigation: farm, dip field, golf, lawn etc.
5,Recycle water
ParameterModel | Pipe | Flow rate T/H | Filter area cm2 | Drain | Water consumption(L) | Motor(KW) | Weight(KG) |
XLQ-50XM | 50 | 20 | 1500 | 50mm | 75 | 0.55 | 85 |
XLQ-80XM | 80 | 50 | 1500 | 50mm | 75 | 0.55 | 87 |
XLQ-100XM | 100 | 80 | 3000 | 50mm | 150 | 0.55 | 210 |
XLQ-125XM | 125 | 100 | 3000 | 50mm | 150 | 0.55 | 212 |
XLQ-150XM | 150 | 150 | 7000 | 50mm | 150 | 0.55 | 212 |
XLQ-200XM | 200 | 300 | 7000 | 50mm | 150 | 0.55 | 220 |
XLQ-250XM | 250 | 450 | 11000 | 80mm | 400 | 0.55 | 395 |
XLQ-300XM | 300 | 600 | 11000 | 80mm | 400 | 0.55 | 405 |
XLQ-350XM | 350 | 900 | 13500 | 80mm | 400 | 0.55 | 625 |
Install way | Horizontal |
Unit capacity | 15-900T/H,Achieve parallel install to achieve big capacity |
Min work pressure | 0.25Mpa |
Max work pressure | 1.0Mpa,1.6Mpa |
Micron | 20-500um |
Control way | Differential pressure, time and manual |
Max temperature | 65ºC (reach to 100ºC if required) |
Back wash time | 50-90S |
Rotating speed | 14-20rpm |
Clean way | Scanning type |
Differential pressure in cleaning | 0.01-0.08Mpa |
Back wash water consumption | Approximate 280-310kg |
Voltage | AC220V |
380V,50Hz,3PH,CONTROLLER: 220V |
Motor power | 0.37Kw |
Material | Carbon steel with anti-corrosion painting |
Screen | Multi stainless steel mesh + pvc structure |
Drain valve | Cast ion with antir-corrosion painting |
PLC Control |
Installation view
Install requirement 1,Keep space for filter install and maintenance.
2,Drainage pipe length not longer than 20m. Avoid more turns off, keep outlet pipe parallel with ground.
Testing
1,Close inlet outlet valve before testing. Open by-pass valve. Wash dirties staying in pipes.
2,Open inlet valve gradually. Let water into filter till air comes out from filter house.
3,Check leak at joint part, check in/outlet pressure gauge. Connect power when comes to system pressure.
4,Set up drainage time based on system pressure data.
5,Open outlet valve gradually if testing is normal. Close by-pass valve back to normal filtering.
6,Observe several differential pressure changes and drainage. Finish testing if normal.
Notice in using
Equipment can through into operation directly, as already has trial testing. Users can adjust settings based on actual use. Change relay's program and parameter is forbidden.
1st operation notice
Follow below steps in 1st operation
Check drainage pipe connection. No up-inclined angle.
Check connection tighten or not.
Check control box in a dry environment.
Connect power cord, green light means normal. Make sure electrical parts is dry. Water is forbidden into control box.
Certificates
Welcome To Inquire, We Will Offer You The Best Items !
Started from 2004, Peide has been concentrating on research and production for water treatment equipment, our founder Mr. Wu has been supplying team work for over 7000 project, and draw lessons from A large number of engineering practice and accumulated rich experience in design and installation. Considering from better cost-efficiency, safety, credibility, we supplied our solutions to our customers, such as Cocacola China, Pepsi China, Siemens, Gates Hydraulic, HSBC, Shanghai Expo Venue, Danone, Kerry food, Kafu, Hair, Lenovo, GE, Benz, Toyota, Hyundai Motor etc.,
For decades, we have been water treatment equipment for food, beverage, pharmacy, hospital, precision electronics, chemical, electric power, surface cleaning, air-conditioner industries. Our customer is mainly in the USA, Japan, South Korea, France, Norway, England, India, Chile, Mexico and other 70 countries.
Mainly Products: UV water sterilizer & disinfection equipment, Water Filter equipment including Bag type filter, Sucking automatic type filter, Automatic brush type filter, Sand filter equipment, Electric scale equipment, Recycling water treatment equipment, Ion stick etc., .
Certificate: ISO: 9001: 2008, CE, China Famous Brand
Sales: 20M RMB/year
Peide is always looking for new ways to increase the value of the products and services we offer to our customers. Our goal is to creat class quality, class service, class management and class environment. Try to make our sky bluer, our ground greener our water cleaner.
