| Prod Model: |
BD/BC-100A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Chest/Deep Freezer |
| Door Type: |
Folding Door |
| Defrost Type: |
Manual Defrost |
| Power Source: |
Electricity |
| Temperature Type: |
Single-temperature |
| Certification: |
ETL |
Product Description
BD/BC-100A Chest freezer, deep freezer, top door commercial freezer
Specifications
Chest freezer with top open door and sigle temperature, Interior lamp is optional!
Chest freezer
Detailed Product Description
BD/BC-100A, BD/BC-100, BD/BC-145, BD/BC-200, BD/BC-300, BD/BC-388, BD/BC-468, BD/BC-568, BD/BC-668
Features:
1. Embossed Al board liner is beautiful, durable and excellent in thermal conduction.
2. A food basket is provided together with the machine, fully utilizing space in the box. Partition screen boards are provided to facilitate the sorted storage of food, saving time and electricity.
3. Thick thermal insulation using advanced foaming technology.
4. Wideband temperature variation design is applied to realize a free selection from the four levels, i. e., cold storage, micro-freezing, freezing and speed freezing. Suitable temperature zone is selected according to different food.
5. The door seal is in embedded design and can be easily removed and convenient for cleaning.
6. Man-machine engineering principle is applied. A balanced hinge is installed on door-frame, so that the door can be opened from any angel.
7. Fully round corners are in safe design, always taking care of you and your family.
8. The door seal strip is inserted inside the frame opening to reduce coolness loss, which is perfectly energy-saving and environmentally friendly.
9. The thick foaming layer is as thick as 70mm and provides an excellent insulation property.
10. The relatively independent and simple system is a best option substituting small-scale refrigerating house.
11. Interior lamp desgin is optional.
Model
|
BD/BC-100A
|
BD/BC-100
|
BD/BC-145
|
BD/BC-200
|
BD/BC-300
|
BD/BC-388
|
BD/BC-468
|
BD/BC-568
|
BD/BC-668
|
Capacity
|
100 L
|
100 L
|
145 L
|
200 L
|
300L
|
388 L
|
468 L
|
568 L
|
668 L
|
Climate class
|
N
|
N
|
N
|
N
|
N
|
N
|
N
|
N
|
N
|
Temperature
|
-18 o C to 10 o C
|
-18 o C to 10 o C
|
-18 o C to 10 o C
|
-18 o C to 10 o C
|
-18 o C to 10 o C
|
-18 o C to 10 o C
|
-18 o C to 10 o C
|
-18 o C to 10 o C
|
-18 o C to 10 o C
|
Inside bottom type
|
Step bottom
|
Step bottom
|
Step bottom
|
Step bottom
|
Step bottom
|
Step bottom
|
Step bottom
|
Step bottom
|
Step bottom
|
Power supply
|
220V/50Hz
|
220V/50Hz
|
220V/50Hz
|
220V/50Hz
|
220V/50Hz
|
220V/50Hz
|
220V/50Hz
|
220V/50Hz
|
220V/50Hz
|
Rated input power
|
102W
|
102W
|
102W
|
128W
|
270W
|
270 W
|
300 W
|
300 W
|
320 W
|
Power consumption
|
0.86 kwh/24h
|
0.86 kwh/24h
|
0.95 kwh/24h
|
1.20 kwh/24h
|
1.23kwh/24h
|
2.20 kwh/24h
|
2.50 kwh/24h
|
2.50 kwh/24h
|
2.84kwh/24h
|
Refrigerant
|
R600a
|
R600a
|
R600a
|
R600a
|
R134a
|
R134a
|
R134a
|
R134a
|
R134a
|
Net weight
|
31 Kg
|
31 Kg
|
36 Kg
|
40 Kg
|
50 Kg
|
67 Kg
|
72 Kg
|
79 Kg
|
80 Kg
|
External dimension (mm)
|
520×535×850
|
621x480x850
|
821×480×850
|
831×610×850
|
1115×610×850
|
1410x642x850
|
1600×642×850
|
1885×642×850
|
1920×755×850
|
Loading quantity
|
240pcs/40HC
|
203pcs/40HC
|
156pcs/40HC
|
128pcs/40HC
|
98pcs/40HC
|
70pcs/40HC
|
62pcs/40HC
|
54pcs/40HC
|
38pcs/40HC
|
