Prod Model: |
BR-RVS7001 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Brand Name: |
Brvision |
Place Of Original: |
Guangdong, China(Mainland) |
Voltage: |
12V |
Warranty: |
12 Months |
Definition: |
420TVL |
Chip: |
CCD |
Waterproof Grade: |
IP68 |
Interface: |
4 Pin Connector |
Product Description
10.1 inch TFT LCD monitor with built-in quad control box
- Built-in quad control box function
- Rear view monitor support four camera inputs
- With remote controller
- Single View/Split view/Quad view selectable
- 7 languages OSD display
- PAL/NTSC optional, MIRROR/NORMAL image optional
- Automatically turn on when the reversing gear is engaged
- Trigger priority: CAM 1>CAM 2>CAM 3>CAM 4
- With high-low voltage protection and short circuit protection
- IR rearview camera
- 10.1 inch TFT LCD monitor ,16:9
- Wide view angle(CR>10): (up/down/left/right): 70/80/80/80
- Resolution:WSVGA 1024 horizonal x 600 vertical pixel
- Color system: PAL/NTSC(selectable)
- Power requirement: 12/24V DC
Standard back view camera
- IP rating : Genuine waterproof & dust resistance grade IP68
- Image Sensors :1/4″Sharp CCD
- Resolution(TV lines) :420TVL
- Lens Angle(Deg.) :120°
* Heater function (optional)
- IR Led for night vision
- Night Vision function: 16pcs LED lamp
- Audio Function: Avilable
- Housing: Sliver/White/Black housing for option
. 20M extension cable ; accessories
. DC 12-24V power supply
BRVISION TECHNOLOGY Co., Ltd is a professional Mobile Electronics and Surveillance developer & supplier in China. We specializing in OEM and ODM vehicle rear view system and surveillance products
Our vehicle system department products include the heavy duty and car reversing system, TFT LCD monitor, License plate camera, wireless Module, DVR recorder camera and etc.
Our surveillance system department products line have PTZ camera, dome camera, box camera, and so on.
It is our mission statement to bring convenience to your life while protecting your safety and property. Above all, BRVISION strives to offer products for all our customer's unique requirements both in China and on the international market. Currently, our products are exported to North America, Europe, the Middle East and all over Asia.
BRVISION has decades of experience of safety and surveillance in the international market place. We can quickly respond to your feedback and are well equipped to meet any and all your requirements.
We specialize in:
. Vehicle Rearview Camera(CCD or CMOS)
. Vehicle TFT LCD Monitor
. Wireless Transmitter and Receiver
. Surveillance Camera
. OEM and ODM Project
BRVISION Certificats: CE, FCC, Emark, ISO9001-2008
