| Prod Model: |
FZY-D |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model: |
150 and 200 |
| Frequency: |
50Hz |
| Phase: |
2 Phase |
| Voltage: |
220V |
| Type: |
Axial Flow Fan |
| Power Supply: |
Electric |
| Application: |
Industrial |
| Remote Control: |
Without Remote Control |
| Timer: |
Without Timer |
| Power: |
<100W |
| Installation: |
Wall Mounted |
| Speed: |
2600r/Min |
| Material: |
Aluminum Alloy Shell, Plastic Blade |
Product Description
Axial flow fan is consists of aluminum alloy shell, plastic blade and electrical machine. It has such advantages of small size, installation convenient, large wind, small vibration and low noise.
The scope of application:
It is mainly used in ground automatic control device, which needs big air flow, and ventilation and heat dispersion of large-scale electric equipment, cabinet and electric welder. It can also be applied for ventilation, breathing and purity in buliding and workshop.
| Type | Voltage | power rating | phase number | input power | electric current | rotate speed |
| 150FZY2-D | 220V | 50HZ | 1 | 30W | 0.15A | 2600r/min |
| 200FZY2-D | 220V | 50HZ | 1 | 65W | 0.30A | 2600r/min |
| 200FZY4-D | 380V | 50HZ | 3 | 65W | 0.18A | 2600r/min |
| Type | Blastvolume | Noise | Weight | Electric power | Insulate | Environmental conditions |
| 150FZY2-D | 5.5m³ /min | 65 | 0.9kg | 1.0/400μ F/V | E | 2 |
| 200FZY2-D | 13m³ /min | 70 | 1.5kg | 1.0/400μ F/V | E | 2 |
| 200FZY4-D | 13m³ /min | 70 | 1.5kg |
| E | 2 |
Shape and Assembly Dimension
|
Size
type
| D
| D1
| D2
| d
| h
| L
|
150FZY2-D
| 150
| 158
| 173± 0.15
| 4.5
| 4.5
| 58.5
|
200FZY2-D
| 200
| 210
| 235± 0.15
| 6.3
| 6.8
| 73.5
|
200FZY4-D
| 200
| 210
| 235± 0.15
| 6.3
| 6.8
| 73.5
|
Remarks: bidirectional fan
|
