| Prod Model: |
G150XG01 V4 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand Name: |
Auo |
| Size: |
15 Inch |
| Resolution: |
1024x768 |
| Backlight: |
Wled |
| Interface: |
Lvds |
| Weight: |
1.12kgs (Max.) |
| Width:Height: |
4:3 |
| Brightness: |
350CD/M2 |
| Contrast Ratio: |
700:1 |
| Operate Temperature: |
-10 to 60 Deg. |
| Type: |
Color |
| Display Technology: |
TFT |
| Viewing Angle: |
TN＋FILM |
| Usage: |
Ideal for Industrial Uses |
Product Description
G150XG01 V4 15 inch LCD screen Features:
1)With original capacitive touch panel integrated;
2)WLED backlight;
3)6-8 bit optional;
4)With LED driver integrated;
5)Inversion show 180 degree;
6)Wide view angle;
7)Backlight replaceable;
8)Backlight life is more than 50k hours;
9)Ideal for industrial use.
AUO industrial grade 15 inch TFT LCD (G150XG01 V4) data sheet:
Module number: G150XG01 V4;
Resolution: 1024X768;
Pixel Pitch: 0.297 X 0.297 (mm);
Active Area: 304.128(H) X 228.096(V) (mm);
View angle: R/L/U/D 80/80/60/80 (Deg);
Mode: TN;
Number of Colors: 262K/16.2M;
Electrical Interface: Digital, LVDS(1CH, 6/8 bit);
Brightness: 350 CD/m2;
Contrast ratio: 700: 1;
Outline dimension: 326.5(W) X 253.5(H) X 15.5(D) (mm);
Gross weight: 1.12 kgs(Max. );
Backlight: WLED;
LED Life (hrs. ): 50K;
Power Consumption (W): 9.63(Typ. );
Supply Voltage (V): 3.3V;
Response time: 8 (ms);
Operate temperature: -10-60 Deg.;
Storage temperature: -30-85 Deg.;
Operate humidity: 5-95 (%RH);
Storage humidity: 5-95 (%RH);
Package: AUO original package; 10 PCS/carton; Carton size: 428X374X351 mm; Gross weight: 13.0 Kgs.
