| Prod Model: |
ASH-200L/E |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Heating Capacity: |
200L |
| Heat Temperature: |
50-70??C |
| Work Environment: |
Common Heat Pump |
| Heat Source: |
Air-source |
| Application: |
Hotels |
| Certification: |
RoHS |
Product Description
NINGBO AKL ELECTRIC CO.,LTD was established in 2002, is a professional R & D, manufacturing all kinds of Air Source Heat Pump Water Heater,Swimming Pool Heat Pump,Air Conditioner,It is located in the port city Ningbo which is a household appliance producing base in China.
| Model | ASH-150L/F | ASH-200L/F | ASH-250L/F |
| Power Supply | V/Ph/Hz | 220V~240V/50Hz |
| Refrigerant | Type | R410A |
| Water tank capacity | L | 150 | 200 | 250 |
| Rated Heating Capacity | kW | 2.2 | 2.2 | 2.2 |
| BTU/h | 7500 | 7500 | 7500 |
| Rated Power input | w | 610 | 610 | 610 |
| Rated current | A | 2.78 | 2.78 | 2.78 |
| COP | w/w | 3.6 | 3.6 | 3.6 |
| Rated Hot Water Output | L/h | 48L/h | 48L/h | 48L/h |
| Auxiliary electric heating | kW | 2(Optional) |
| Rated water temp |
| 30~55 |
| Max Hot Water Temp |
| 65 |
| Operation temp range |
| -7~45 |
| Level against electric shock | I | I | I |
| Water-proof grade | IP×4 | IP×4 | IP×4 |
| Water Pipe Dimension | inch | 3/4. |
| Noise | dB(A) | 48 | 48 | 48 |
| weight | kg | 75 | 86 | 98 |
| Net Dimension(DxH) | mm | Φ510*1660 | Φ570*1747 | Φ570*2037 |
| Packing Dimension(LxDxH) | mm | 595*580*1755 | 710*680*1845 | 710*680*2132 |
| Container loading qty ( 20GP/40HQ) | pcs | 27/54. | 24/48. | 24/48. |
NINGBO AKL-Histar Electric Co., Ltd was founded in 2004. Main products consist of various electric appliance, and more than 70 kinds in all. with complete specifications, novel models, products are extensively applied to home and commercial department. Our products export to the whole world. Europe, South & North America, Southeast Asia, Africa and Middle East. Our factory obtains reliance and praise from customers and societies with excellent quality and competitive price.
Our company has passed CE, RoHS. COC, SAA. SONCAP. UL. SASO Certificate. For purpose to control products' quality well, we develop a whole set of standard testing equipment by ourselves.
We always insist on the management aim of "quality first, customers supreme", strive for top grade products and offer first rate service. We sincerely welcome the old and new customers to visit our factory, negotiate business, cooperate extensively and achieve common prosperity.
