| Prod Model: |
SYWF-400 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Air Volume: |
805 |
| Impeller Testing: |
Static and Dynamic Balancing Adjusting |
| Environment: |
Low Noise |
| Noise: |
60db |
| Featuer: |
High Efficiency,Large Volume |
| Motor Protection: |
Thermal Protection Device |
| Thermal Protection Device: |
50Hz/60Hz |
| Impeller: |
Forward Curved Blades |
| Static Pressure: |
0PA |
| IP Ratation: |
56 |
| Blade Material: |
Stainless Steel |
| Electric Current Type: |
AC |
| Mounting: |
Wall Fan |
| Certification: |
SGS |
Product Description
Product Description
Fetures:
1. The average working life of motors is more than 30000 hours.
2. The electrical motor uses the interior fuse protection dovice, safe and reliable.
3. The front louver can effectively prevent the rain dust entry.
4. The fashion design enables the large air volume, low noise and run stable.
5. The electrical motor uses the interior fuse protection dovice, safe and reliable.
6. The structure component is stamped by high quality steel sheet, stiffness well, weight light, appearance elegant and installation favorable
7. All motors in our factory have attained CE approval in Europe and CCC safety certificate in China.
8. The standard length of the electrical wire on the fan is 1.5m, ND we can also provide connection box to fan motors for clients' choice
Applications
Industrial boiler blowing air, Industrial boiler inducing air, Industrial boiler waste gas dust collecting.
Industrial kilns
Ventilating
Cooling and heat dissipation
Air purification and industrial waste gas treatment, Industrial dust collector.
Air purification of hazardous working environment (Paper making production line, Electrolytic aluminium production line, Textile mill).
Metal smelting
Gas and materials delivery
Other Recovery of industrial waste gas, Supply air and drying of food and drug production line.
| Product Model: | KHG1-30 | KHG1-35 | KHG1-40 | KHG1-45 | KHG1-50 | KHG1-60 |
| Product Spec | 12" | 14" | 16" | 18" | 20" | 24" |
| Motor(mm) | 120*20 | 120*20 | 120*22 | 120*22 | 120*24 | 120*24 |
| Power(W): | 45 | 70 | 130 | 200 | 350 | 500 |
| Speed(r/min) | 1300 | 1300 | 1350 | 1350 | 1250 | 1250 |
| Air Volume(m 3 /h) | 1080 | 2280 | 2880 | 3600 | 5700 | 8700 |
| Packing Size(CM): | 85.5*38*38.5 | 83*43*44 | 50*50*25 | 57*57*28 | 61.5*61.5*30 | 71*71*30 |
| Packing Quantity(PCS): | 5 | 4 | 1 | 1 | 1 | 1 |
| Loading QTY(pcs) | 1080/2520/2520 | 700/1400/1680 | 396/864/960 | 320/672/756 | 189/399/456 | 168/336/384 |
Shanghai Shenglin is a professional supplier in China specializes in refrigeration units and parts. Now we have two factories. One is mainly manufacturing condensers and evaporators, the other one is mainly manufacturing central air conditioners like roof-top air conditioners, precision air conditioners and air handing units. Both of our factories are ISO certificated.
Our condensers and evaporators can be widely used in air conditioners, heat pumps, fan coils, air handing units, drinking machines, ice makers, dehumidifiers, laser machines, welding machines and other area. We can not only manufacture copper pipe condensers and evaporators, but also manufacture stainless steel pipe and aluminum pipe condensers and evaporators.
Our rooftop air conditioners are easy to be installed and maintained. As they are installed on the top roof, so they will not spare the room space. They are weather proof and have high efficiency.
Our precision air conditioner can control temperature in ± 1ºC and humidity in ± 5%. It can be used in data center and telecom base station. Most parts are world famous brand.
Our products have been exported to Europe, North of America, Middle East, South of Africa and southeast Asia.
We sincerely welcome customers all over the world to visit our company and set up business relationship for mutual benefit.
