Product Description
Our company have all kinds of air conditioner, compressor, fan, compressor for bus (6~13meters)
We have our after-sale station all over the world.
Rated cooling Capacity 12~31Kw
Max cooling Capacity 12~35 Kw
Compressor displacement 674CC/r(Depend system)
Refrigerant R134A
Evaporating airflow rate 5400m3/h
Condensation airflow rate 11400m3/h
Total power consumption 86A 27V
Outer size 4635*1860*232
Fresh air flow 1300 m3/h
Weight 270kg
A/C STANDARD PARTS(Can choose).
Type of vehicle Air conditioner model Suitable auto length Mounting means Type of vehicle Air conditioner model Suitable
A/Cmodel bus length A/Cmode Bus lenghth TCR720 6~7 Meters TCR100 10~11M
TCR740 7~8M TCR120 12~13M
TCR793 7~8 M TCRG820 8~9M
TCR796 7~8 M TCRG890 9M
TCR840 8~9 M TCRG100 City Bus
TCR896 8~9 M TCRG110 City Bus
TCR930 9~10 M TCRG120 City Bus
1 Compressor FK40/470N Germany
2 The evaporator fan spal
3 The condenser fan spal
4 Fresh air motor Belimo Switzerland
5 Expansion valve Danfoss Denmark
6 Cut-off valve Danfoss Denmark
7 The drying apparatus Danfoss Denmark
8 The oil watch lens Danfoss Denmark
9 Condenser TC China
10 Evaporator TC China
11 Outer pipeline TC China
16 Display Samsung Korea
17 Electrical Connector of lines AMP U. S. A
18 Electronic antisepsis equipment TC China
19 Compressor bracket TC China
20 bearing NSK Japan
21 Charging valve Tacific U. S. A
22 Relay Siemens Germany
23 shell TC China
24 Clutch TC China.
Our company was invested by Xin Zhongnan International Investment Group which in Hong Kong. We provide specialized service for bus which long is 6 to 13 meters. We are planning to develop business cars and cars. Our factory covers an area of 33350 m2 in Suzhou Singapore Industrial Zone. We passed the ISO9001 smoothly: The attestation of International Quality System 2000 and the Center of Chinese Attestation to car product to the quality of the refrigeration equipments. Now the company is working for the ISO/TSI16949: 2002 of the quality system. At the present time among 60 percent of our employees are technology workers. Our company had established the independent research and design center, and our owns the first-class product line with the throughput of 10000.
