| Prod Model: |
P8. P10 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certificate: |
CE; FCC; CCC; UL; RoHS |
| Tube Chip Color: |
Full Color |
| Display Function: |
Video Display |
| Pixel Pitch: |
4mm |
| Pixel Configuration: |
1R,1G,1B |
| Pixel Density: |
40,000 dots / m² |
| Scanning Mode: |
1/8 Scan |
| Application: |
Advertising |
| IP Rating: |
IP43 |
| Certification: |
CCC |
| System Operating Platform: |
XP,2000, 98 |
Product Description
Product features
1. New look, new vision, it is very like flat-panel TV in the shape and it has powerful capabilities of multimedia playback.
2. Its viewing distance is 2m-50m, far ahead of the flat-panel TV.
3. 16:9 standard theater mode display size without distorting, not tear fully retain the highest quality of the video screen
4. There are fans that in the display, which makes the display work safely.
5. We adopt the All-digital stamping technology and make the display body as slim as 76mm.
6. We offer 500MB Mass storage, which will make you program more wonderful.
7. We provide kinds of software and it will be easy to learn and use, anyone can handle it easily.
8. We put a automatic environment sensing device in the display, it will adjust the brightness of the display Automatically and can display the temperature and humidity.
9. Its brightness is more than 2000cmd which is 6.6 times that of the flat-panel TV. It will not be affected by the environment brightness easily, which makes the screen more beautiful.
10. 4096 gray HD smooth video playback, Stunning visual experience.
11. It will full support for the various forms of video, animation, text and tables.
12. It can display the digital clock.
13. There are 3G wireless modules in it, which makes the data transmission more fast.
14. We use the wireless remote to control it, which makes it easy for us to change the channels.
15. We put 2mm thickness of ultra-thin tempered glass in the surface of it, which protect it from the rain and dust.
16. You can choose the installation as you like, wall-mounted or column.
17. We adopt the new design, in front of it was a panel, the middle is the cabinet and the back is a panel too, which makes it easy for us to assemble.
18. Aviation-style power plug, unique protection design make it more safe while using.
19. We adopt the U disk to transmit the information and it won't be limited by the internet.
20. Built-in USB integrated sound and stereo surround sound box makes the screen waving with the sound.
| parameters of p4 |
|
| no | item | parameter |
| pixel |
| 1 | pixel pitch | 4mm |
| 2 | resolution | 224x128 |
| 3 | horizontal axis | 160° |
| 4 | vertical axis | 160° |
| 5 | pixelcomposition | 1R1G1B |
| 6 | led pixel type | SMD 2020 |
| 7 | white brightness | 2000-2500cd/m |
| 8 | white balance coordinates | x=0.29,y=0.31 |
| 9 | color temperature | 8000k |
| 10 | contrast | 64000:1 |
| 11 | gray scale/color | 16.7M |
| 12 | refresh rate | 480HZ |
| 13 | viewing distance | 2-50M |
| Module |
|
| 1 | resolition | 32x32 |
| 2 | dimension | 128mmx128mm |
| 3 | type | Synergetic lamp and drive |
| 4 | scan method | 1/8 Scan |
| 5 | drive method | Constant current |
| 6 | working voltage | 5v |
| 7 | maximum consumption | 25W |
| 8 | average consumption | 6.25W |
| 9 | shell material | PC |
| 10 | mask material | PC |
| apperance of size |
|
| 1 | displaying size | 896mmx512mm |
| 2 | cabinet dimension | 1188x602x76mm |
| 3 | cabinet material | aluminum alloy |
| 4 | cabinet color | black |
| 5 | supporting brachet size | 1298mmx802mm |
| 6 | supporting brachet material | iron |
| power supply |
|
| 1 | input voltage | 100v/AV |
| 2 | input rate | 50-60HZ |
| 3 | maximum consumption | 420w |
| 4 | average consumption | 105w |
| application environment |
|
| 1 | application environment | indoor/outdoor |
| 2 | working temperature |
|
| 3 | working humitidy | 10%-90% |
| 4 | stock humitidy |
|
| 5 | protection grade | the front face IP65 ,the back face IP43 |
| function |
|
| 1 | controle method | asynchronous display |
| 2 | Built-in capacity | 500MB |
| 3 | U disk play | 8GB(maximum |
| 4 | Broadcast regularly | support |
| 5 | Brightness adjustment | auto/6 levelsoftware |
| 6 | Temperature and humidity display | support |
| 7 | Infrared remote control switch programs | support |
| 8 | Video format | supportAVI,WMV ,MPG,MOV,DAT,VOB,MP4,FLV |
| 9 | Animation format | GIF,SWF |
| 10 | picture format | SUPPORT BMP.JPG,GIP,WMF,ICO |
| 11 | text | TXT,RTF,single text,static text and Multiple lines of text |
| 12 | form | support |
| 13 | time | suport digital clock display |
| 14 | partition display | any |
| 15 | MTBF | ≥10000 hours |
| 16 | Longevity | ≥10000 hours |
| sound |
|
| Built-in speakers | support |
| Channel | double channel |
| Volume | 85db |
| power | 1.2wx2 |
| Frequency Response | 200hz-18hz |
| Sensitivity | 800db/1w/0.5m |
| operating system |
|
| operating system | windows7,xp |
| software | led editor |
SkyMax Display Technologies Co., Ltd is a world class advanced enterprise specialized in designing, researching and manufacturing LED lamps, LED Display and LED lighting. We are service enterprise in LED display field and focusing on offering LED projects solution. The company founded in 2006 and located in Zhongshan city which is famous as 'The China lighting city'.
SkyMax has 30, 000 square meters of air conditioned workshop area including dustless rooms, anti-static workshop, LED module aging room, LED display aging room. The factory is also equipped with all new and most advanced world first-class machines for LED automatic production line: American ASM auto-die bonder, ASM auto-wire bonder, Taiwan auto-encapsulate machine, Taiwan Chang-Yu handler, automatic LED braider, America Global automatic LED inserting machine, Japan JUKI automatic SMD machine, N2 lead-free relow soldering system, N2 lead-free dual wave soldering system. The company also has the machines testing system, including: Automatic PCB painting machine, automatic lamps adjusting machine, automatic rubber filling machine, automatic molding machine as well as high and low temperature testing machines, constant temperature and humidity machine, salt-spraying machine, shaking machine, waterproof testing machine. We have a group of professional, stable, pragmatic and innovative high-quality research and development team, which forms LED devices production to terminal manufacturing complete LED chain. SkyMax chooses high point, high standards, strict demand, in strict accordance with ISO9001: 2008 quality Guarantee system operation, and meticulous management into all aspects of production to ensure the quality of our products at the industry-leading position.
The company adopts advanced technology and management, producing a wide range of light-emitting diode, designing and manufacturing various electronic LED display, LED lighting to suit indoor and outdoor applications such as various stadiums, airports, wharf, stations, commercial system, exhibition centers, advertising etc. The products have been sold to America, Europe, South America, East Europe, Middle East, HongKong, Macao, the quality and customer service has won the recognition and acclaim. We are willing to work together with you to create a global production base for high-quality LED.
The company complies with the time development, promotes the scientific innovation and the time positively connects rails, the company quality system has updated into ISO9001: 2008, all products have got the certification of CE, FCC, RoHS ect.
To be the popular brand in LED business line is the final target of SkyMax. SkyMax means 'Mountain mind, Contains infinite; Green trees, Indomitable', SkyMax staff take 'honest, contains, thanks giving, responsibility' as the core values. Take 'creating professional, reliable products' as the duty. Offer the best products, best after-sale service. All SkyMax staff work together and let SkyMax products be popular in the world.
