| Prod Model: |
Master-Q |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Feed Water: |
Tap Water |
| Flow Rate: |
15 Liter/Hour* |
| Heavy Metal Ion(Ppb): |
<0.1ppb |
| Toc: |
<30ppb |
| Bacteria: |
<1cfu/Ml |
| Granular(>0.22um): |
<1/Ml |
| Outlet: |
RO Water, Di Water |
| Dimension: |
Lxwxh:50X36X54cm/ About22kg |
| Power: |
100-250V, 50-60Hz/120W |
Product Description
1)Application
Feed for ultra-pure water sytem, Media preparation, Fine chemical industry, Preparation of chemical solutions used
With totrators, Buffer preparation, ion chromatography Photographic flush, Test chamber, meteorological laboratory
Equipment, Hydrogen generator, humidifier etc.
2)Flow Schematic PF+KDF+AC+RO+AC+DI
LV. 1 5μ M spun PP filter
LV. 2 Mixed KDF filter
LV. 3 Granular active carbon filter
LV. 4 100GPD RO membrane
LV. 5 Post active carbon filter
LV. 6 Mixed bed resin cartridge× 3
3)After-sales service
· The products customers buy from our company enjoy repair service since the day of purchase. In on year from the purchasing day, our company is obliged to replace components free of charge due to non-human-behavior factors except:
(1). Damage caused by maloperation or use in abnormal situations.
(2). Disassembly any part of the machine or human-behavior damage.
(3). Not repaired by our serviceman.
4)Main Market
Asia, The Middle East, Eastern Europe and South Africa
|
n Master-Q series deionized pure water system(Tap water inlet) |
|
Model |
Deionized water purification system |
|
Master-Q |
Master-Q UT |
Master-Q plus |
Master-Q plus UT |
|
Flow procedure |
PF+KDF+AC+RO+AC+DI |
PF+KDF+AC+RO + UV+AC + DI +TF |
PF+KDF+AC+RO+AC+DI |
PF+KDF+AC+RO + UV+AC + DI +TF |
|
Application |
Ware washing, Agricultural expe, General biological expe, Aquatic products feeding, Inlet water for Ultra pure water machine, Inlet water for sterilizer/T&H chamber, Buffer disposing, Aseptic drinking water, Physical and chemical analysis, Fine chemistry industry, Inlet water for Ultra pure water machine, GC/HPLC, Pharmacy research, Medicine examining |
|
DI water quality |
Resistivity |
16-18.2MΩ.cm |
|
Heavy metal ions |
0.1ppb |
|
TOC |
30 ppb |
|
Bacteria |
- |
1CFU/ml |
- |
1CFU/ml |
|
Particle(>0.22μm) |
- |
1/ml |
- |
1/ml |
|
RO water quality |
< TDS(ppm, mg/l) of tap water×5% |
Technical
specification |
Output(25 degrees celsius) |
15 Liters/hour* |
30 Liters/hour |
|
Flow rate |
2 Lliters/min(with pressure tank) |
|
Pure water outlet |
RO water, deionized water |
|
Dimension/weight |
Length×Width×Height:50×36×54cm / 20-30Kg |
|
Electric requirements |
AC110-220V,50/60Hz,120W |
Control
system |
Mode display |
Power on, program, inlet rinse, producing, full, circle, regular outlet, disinfection, consumables replacing remind |
|
Safety |
Low pressure and full water alarm, password, auto-reset, outlet forbidden when alarm or disinfection |
|
System monitor |
Display quality of feed water, RO water and ultrapure water, temperature, used and left time of consumables |
|
Feed water requirements |
Tap water, inlet TDS<200 ppm,5-45degrees celsius,1.0-4.0kgf/cm 2
(if inlet TDS>200ppm, extra pretreatment is recommended) |
Purification
system |
Pretreatment unit |
5μm spun fiber filter×1+Kinetic degradation fluxion filter×1+Granular active carbon filter×1 |
|
RO unit |
100 GPD RO membrane×1 ( Plus model: 100 GPD RO membrane×2) |
|
Subsequent unit |
Post active carbon filter×1+Mixed bed resin cartridge×3{Plus model: Mixed bed resin cartridge×4}
UT model:+254nm wavelength UV lamp cartridge×1+(0.45+0.1) μm terminal filter×1 |
|
Standard configuration |
Main body(including:1 set cartridge)+4 gallon tank+ accessory box |
Hitech Instruments Co., Ltd, established in 2003, specializes in manufacturing laboratory water purification systems and related apparatus. Except for the small capacity lab water purification systems, we also provide the service of large or medium-sized water treatment engineering design, complete supply, installation debugging, technical reform and technical training etc. In addition, we can provide the professional training of the lab water knowledge, and optimize the existing water purification system to help customers to reduce the cost and guarantee the stable pure water supply.
With tap water inlet, integrating various advanced water purification technologies and process control methods, our water purification systems can completely meet, even exceed, the pure water standard of ASTM, NCCLS Class I etc. It can meet the meet of advanced lab water use for different purpose. It can be widely used in the field of chemistry, biology, pharmacy, medicine, micro-electronics, semiconductor etc, meeting the application requirements of spectral analysis, chromatographic analysis, cell culture, protein purification and molecular biology.
We will constantly bring in new technology, and devote ourselves to the development of new products in order to cover diversified demands from clients. We will provide comprehensive solutions for the lab pure water with professional pre-sales support and impeccable after-sales service.
We aim to integrate products with the world market, establish first-class brand by excellent quality and gain market shares by top brand.
