| Prod Model: |
AMG-07PPC83T2 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Luminance(CD/M2): |
300nits |
| Contrast Ratio: |
500:1 |
| Pixel Pitch (Mm): |
0.0635X0.1905 |
| Display Resolution (Pixel): |
800X480 |
| Viewing Angle: |
140(H)X120(V) |
| Type: |
TFT |
| Application: |
Kiosk, Gaming, Industrial Control |
| Widescreen: |
Not Widescreen |
| Feature: |
All in One |
| Response Time: |
30ms |
| 3D: |
Not 3D |
| Aspect Ratio: |
10:6 |
| Optimum Resolution: |
800X480 |
| Screen Size: |
7" |
| Interface Type: |
VGA, DVI, AV, S-Video, HDMI |
Product Description
Specifications:
CPU:AMD Geode@ Lx800 processor,up to 500 MHz
Memory:On Board 256M Double Data Rate(DDR)
CF Card:ASA x 8GB
PS/2 port:PS/2 mouse and keyboard port
VGA port:1xVGA port
COM ports:Default x 2 COM
USB 2.0 ports:Default x 4 USB
LPT port:1xLPT port
CF port:1xCF port
Ethernet ports:1x10/100Mbps Ethernet interface
Audio:MIC-IN,Line-out,Line-in
|
Processor System |
CPU |
AMD Geode@ Lx800 processor,up to 500 MHz |
|
Memory |
On Board 256M Double Data Rate(DDR) |
|
CF Card |
ASA x 8GB |
|
PS/2 port |
PS/2 mouse and keyboard port |
|
VGA port |
1xVGA port |
|
COM ports |
Default x 2 COM |
|
USB 2.0 ports |
Default x 4 USB |
|
LPT port |
1xLPT port |
|
CF port |
1xCF port |
|
Ethernet ports |
1x10/100Mbps Ethernet interface |
|
Audio |
MIC-IN,Line-out,Line-in |
|
LCD Display |
Display Type/ Size(Diagonal) |
Color TTL LCD/7" |
|
Max Resolution |
800x480 |
|
Support Color |
262K Colors |
|
Luminance(CD/M2) |
300 |
|
Contrast Ratio |
500:1 |
|
Pixel Pitch (mm) |
0.0635x0.1905 |
|
Viewing Angle |
140(H);120(V) |
|
Touch screen(optional) |
Type |
Resistive (USB/RS232) |
|
Power supply |
Use connector |
4pin USB2.0 |
|
Input Voltage |
AC 100~240V 4A 47~63Hz |
|
Output Rating |
10W(max) |
|
Ouput Voltage |
+5V 2A |
|
Temperature Range |
Operating Temperature |
0~50°C |
|
Storage Temperature |
-10~60°C |
|
Relative Humidity |
5(%RH)~90(%RH) |
Amongo DIsplay Technology (Shenzhen) Co., Ltd., is a leading manufacturer specialized in designing & producing Industrial LCD Monitor, Open Frame, Touching monitor and Panel PC and etc., we developed more than 300 models LCD items as well as A/D board and inverter board. The main application is for ATM, Self-service Kiosk, Digital Signage, Gaming, POS, Medical Treatment, Media Player and other industrial control area. Any OEM product is available.
With years professional experience in industrial LCD display, strong R&D teamwork and excellent quality control system, we had cooperated successfully with some of biggest ATM manufacturers worldwide. With a large production capacity, it's available for us to do the delivery in a short time.
Amongo would like to develop together with all our customer strongly. We aim at our "good quality" "speed service" "professional and innovative work" helping you to create higher values.
