| Prod Model: |
PAD60 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Size: |
210mm X 94mm X 376mm |
| Weight: |
5.82kg |
| Colour: |
Black |
| Type: |
Professional Amplifier |
| Usage: |
AV |
| Tube Type: |
Transistor Amplifier |
| Function: |
Mixer Amplifier |
| Voltage: |
110~125V AC or 220~230 AC, 50/60Hz |
| Used For: |
Commercial or Professional |
Product Description
Product description
PAD-60 is the high performance audio amplifier which are designed for commercial and industrial public address applications. This type is the standard mount design, rated power is 60W to provide a wide selection for different sound system. Both balanced and unbalanced line inputs are selectable, 25v, 70v and 8ohm are selectable for different speaker installation matching. Complete protection includes short circuit, overload and overheat automatic protection.
Features
1. standard mount design, humanistic design, exquisite technique, show the top grade quality
2. Unbalanced 1 TRS type line input, unbalanced 1 line TRS output
3. Balanced 1 ×LR type line input, balanced 1 ×LR type line output
4. The panel has volume adjustment knob, the back board has switch, turn off the switch when many equipment are connected to eliminate the circuit noise of earth wire
5. Build-in short circuit, overload and overheat automatic protection
Application and management
Applied in airport, station, coffee shop, market, square, school, park, district and other places.
Physic and environment parameter
power supply
110~125V AC or 220~230V AC,50/60Hz
Rated power output
60W
THD
Less than 1% at 1 kHz
Frequency Response
50~20,000Hz(±3dB)
volume control
Bass: ±10dB at 100Hz
Treble: ±10dB at 10 KHz
Output
Pre-Out
0dB,600Ω Unbalanced, RCA pin jack
Liner 1,2 output
0dB, 600Ω Unbalanced, RCA pin jack
Speaker Selection Outputs
Zone2: 8Ω at 1.5 Watts & 600Ω line level a 1.5V
Direct output
High Impedance: 70V\25V screw termina
Low Impedance: 8Ω screw terminal
Input
Liner input
316mV (-10dBV) 10kΩ (optional 600Ω transformer available) balanced Phenix
MIC
0.316 ~ 3.16mV (-50 ~ -30dBV) balanced Phenix Input
AUX 1
316mV (10dBV) 10kΩ Unbalanced RCA Summing Line
AUX 3:
316mV (10dBV) 10kΩ Unbalanced RCA Summing Line
110v~125V or 220~230V switch by the on/off button
Port allocation
1~5 line microphone balanced or linear balanced input, input sensibility:linear 316mV microphone 3.16mV;
2\3 line RCA liner input, input sensibility: 316mV
8Ω,25V,70V output terminal multi-impedance output
Pre RCA output 1V 600Ω;
Line 1 2 RCA linear output 1V 600Ω;
Zone 2 linear output 1.5V 600Ωor 8Ω1.5W;
