| Prod Model: |
60T/24H |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Capacity(Kg/24h): |
60000 |
| Ice: |
Flake |
| Size (Mm): |
5500*3010*3358 |
| Weight: |
12000 |
| Control: |
Electric |
| Power: |
200W-400W |
| Structure: |
Integral Type |
| Material: |
Stainless Steel |
| Application: |
Household |
| Condensing Mode: |
Air-Cooled |
| Filtering Device: |
With Filtering Device |
| Automatic Cleaning Device: |
With Automatic Cleaning Device |
| Ice Shape: |
Cube, Tube, Flake, Plate, Snow, Block |
Product Description
Flake ice machine(commercial)
Application Field:
Supermarkets, hotels, bars, etc
Slaughtering industry
Fishery cooling and packing
Food processing
Fresh preservation for fruit, vegetable, etc
Pharmaceutical application
Commercial Flake Ice Machine Features:
Reasonable Design
NANBEI ice machine is with integrated structure design for saving installation space, and commercial flake ice machine equips with corrosion-resistant ice storage bin.
Stability
NANBEI always aims at researching and manufacturing high efficient and energy-saving refrigeration system; the flake ice machine adopted international ice machine processing technology and experience, and it can produce quality flake ice and constantly operate over 20,000 hours without failure.
Sanitation
NANBEI flake ice machine is made of stainless steel, pure aluminium alloy or PE material; flake ice is made inside evaporator so it is not exposed to ambient conditions and it drops into ice bin without mechanical handling, its hygiene level reaches international standards of HACCP and FDA.
Water & Energy Saving
NANBEI flake ice machine recycles all unfrozen water back to the ice machine so as to ensure all water is converted to ice and save water resources; Our unique evaporator processing technology makes it better heat exchange efficiency and saves more energy, moreover our patented internally-scraping ice scraper can help reduce energy consumption.
Parameters:
| Commercial Flake Ice Machine Technical Specifications |
| Model | Capacity (tons/24h) | Refrigeration Capacity (kw) | Total Power | Weight | Dimension (L*W*H)(mm) |
| ZNPB0.5Z-DF/F | 0.5 | 3.05 | 2.27 KW | 160 kg | 1310*1050*1882 |
| ZNPB1.0Z-DF/F | 1 | 6.25 | 4.21 KW | 210 kg | 1310*1050*2055 |
| ZNPB1.5Z-DF/F | 1.5 | 8.15 | 5.42 KW | 330 kg | 1650*1460*2044 |
| ZNPB2.0Z-DF/F | 2 | 10.32 | 6.72 KW | 360 kg | 1650*1460*2076 |
| ZNPB2.5Z-DF/F | 2.5 | 13.12 | 8.52 KW | 390 kg | 1650*1460*2095 |
| ZNPB3.0Z-DF/F | 3 | 19.17 | 9.82 kW | 470 kg | 1650*1460*2186 |
Note:23.0
1) Standard Supply Power: 380V/50Hz/3Phase. Ice machine can be customized upon non-standard power.
2) Cooling System: Air Cooling System
3) Supply Water: Fresh Water
4) Refrigerant: R22/R404a
5) Ice Thickness: 1.5~2mm
6) Standard Working Condition: Ambient temperature: 25ºC; Water supply temperature: 16ºC; Evaporation temperature: -20ºC.
7) Applicable Working Condition: Ambient temperature: 5~40ºC; Water supply temperature: 0~40ºC.
8) The dimension includes flake ice machine and ice storage bin.
9) Specifications are subject to change without notice.
Industrial Flake Ice Machine
Application Field:
Aquatic product processing
Medium and large chain supermarket
Fresh preservation and cooling field application
Concrete cooling project
Medical facilities
Dye chemical industry
Mine temperature reduction
Industrial Flake Ice Machine Features:
Reasonable Design
NANBEI ice machine is with integrated structure design, and all our equipments are designed on the basis of modules, so the spot maintenance is simple by removing the old parts and install the new ones. Furthermore we always give consideration to how to conveniently move the ice machine to other places.
High Stability
NANBEI always aims at researching and manufacturing high efficient and energy-saving refrigeration system; the flake ice machine adopted international ice machine processing technology and experience, it can produce quality flake ice and constantly operate over 20,000 hours without failure.
Sanitation
NANBEI flake ice machine is made of stainless steel, pure aluminium alloy or PE material; flake ice is made inside evaporator so it is not exposed to ambient conditions, its hygiene level reaches international standards of HACCP and FDA.
Water & Energy Saving
NANBEI flake ice machine recycles all unfrozen water back to the ice machine so as to ensure all water is converted to ice and save water resources; Our unique evaporator processing technology makes it better heat exchange efficiency and saves more energy, moreover our patented internally-scraping ice scraper can help reduce energy consumption.
Parameters:
| Industrial Flake Ice Machine Technical Specifications |
| Model | Capacity(tons/24h) | Refrigeration Capacity (kW) | Total Power | Weight | Dimension(L*W*H)(mm) |
| ZNPB3.0Z-DS/F | 3 | 19.17 | 9.82 kW | 470 kg | 1615*1015*1120 |
| ZNPB5.0Z-DS/F | 5 | 28.8 | 15.28 kW | 1100 kg | 1850*1370*1373 |
| ZNPB8.0Z-DS/F | 8 | 43.2 | 22.79 kW | 1300 kg | 2300*1650*1525 |
| ZNPB10Z-DS/F | 10 | 51.5 | 29.17 kW | 1500 kg | 2300*1650*1745 |
| ZNPB15Z-DS/F | 15 | 106.6 | 55.47 kW | 3200 kg | 3200*2010*2061 |
| ZNPB20Z-DS/F | 20 | 113.6 | 65.57 kW | 4200 kg | 3400*2180*2370 |
| ZNPB25Z-DS/F | 25 | 154.8 | 77.25 kW | 5000 kg | 3800*2540*2452 |
| ZNPB30Z-DS/F | 30 | 184.5 | 92.40 kW | 6000 kg | 4500*2540*2772 |
| ZNPB35Z-DS/F | 35 | 219.5 | 108.35 kW | 6500 kg | 4780*3010*2658 |
| ZNPB40Z-DS/F | 40 | 253.8 | 121.85 kW | 7500 kg | 5000*3010*2818 |
| ZNPB50Z-DS/F | 50 | 329.1 | 160.15 kW | 10000 kg | 5000*3010*3158 |
| ZNPB60Z-DS/F | 60 | 393.7 | 189.35 kW | 12000 kg | 5500*3010*3358 |
Note:
1) Standard Supply Power: 380V/50Hz/3Phase. Ice machine can be customized upon non-standard power.
2) Cooling System: Air/Water Cooling System
3) Supply Water: Fresh Water
4) Refrigerant: R22/R404a
5) Ice Thickness: 1.5~2mm
6) Standard Working Condition: Ambient temperature: 25ºC; Water supply temperature: 16ºC; Evaporation temperature: -20ºC.
7) Applicable Working Condition: Ambient temperature: 5~40ºC; Water supply temperature: 0~40ºC.
8) Specifications are subject to change without notice.
