| Prod Model: |
ST15T |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Capacity(Kg/24h): |
15000 |
| Ice: |
Tube |
| Compressor: |
Bitzer |
| Cooling Capacity: |
109.5kw |
| Control: |
Electric |
| Power: |
>400W |
| Structure: |
Integral Type |
| Material: |
Stainless Steel |
| Application: |
Household |
| Condensing Mode: |
Air-Cooled |
| Filtering Device: |
With Filtering Device |
| Automatic Cleaning Device: |
With Automatic Cleaning Device |
| Ice Shape: |
Cube, Tube, Flake, Plate, Snow, Block, Graular |
Product Description
Application:
1 Human consumption, used in coffee shop, bar, hotel, fast food shop and so on.(crystal ice tubes).Aquatic industry, for freezing and preserving fish, seafood and so on(white color ice tubes)
2 Tube ice can be white color or crystal, compared with flake ice , tube ice has longer melting time
Features:
1.Ice daily capacity range: average level 1000kg, from 980kg to 1100kg depends on the local temperature;
2.Evaporator materials: stainless steel 304, corrosion-resistant, making the ice clean, health, tasteless, sanitary;
3.External diameter: 22mm (European Market recommended) 35mm(Southeast Asia Market recommended) 29mm(General);
4. Inner hole diameter: 5mm to 10mm, adjusted to ice-making time, for a good air permeability and long storage life.
Use hot Freon gas to make ice fall off fast with the whole process takes only 150-180 seconds
1 After the ice is off, the water of low temperature is used for ice-making, saving energy consumption and increasing the volume of production of ice
2 With the unique water distributive pan and air mouth, the water can evenly flow on the tube wall of the evaporator spirally, so it improves the efficiency of heat transfer
3 The use of air pressure control excludes the risk of rupture of the evaporator tube and the tube ice diameter can be adjusted according to customers'needs
4 Half-full liquid: liquid level controller which manages liquid supply of refrigerant makes the system more stable.
Technical parameters:
Model |
Daily output |
Cooling capacity |
Compressor |
Refrigerants |
Total power |
Power supply |
Cooling way |
Dimension(length*width*height) |
ST1T |
1.0T/D |
7.74KW |
Bitzer |
R404A |
6KW |
380V |
Air cooling |
1400x800x1800mm |
ST2T |
2.0T/D |
15.45KW |
Bitzer |
R404A |
8.36KW |
380V |
Air cooling |
1600x800x2000mm |
ST3T |
3.0T/D |
24.55KW |
Bitzer |
R404A |
11.01KW |
380V |
Air cooling
Water cooling |
1700x920x2000mm |
ST5T |
5.0T/D |
36.42KW |
Bitzer |
R404A |
16.03KW |
380V |
Air cooling
Water cooling |
1700x1200x2200mm |
ST8T |
8.0T/D |
52.65KW |
Bitzer |
R404A |
24.55KW |
380V |
Air cooling
Water cooling |
2000x1450x2200mm |
ST10T |
10T/D |
74.31KW |
Bitzer |
R404A |
34.95KW |
380V |
unit
evaporator
Cooling tower |
1800x1500x1600mm
1180x1180x3500mm
Φ2000×2410mm |
ST15T |
15T/D |
109.5KW |
Bitzer |
R404A |
48.42KW |
380V |
unit
evaporator
Cooling tower |
2000×1800×1600mm
1250×1250×4200mm
Φ2175×2565mm |
Warranty:
One year after shipping, within the warranty period, all the cost of fault parts in materials and workmanship, labor and related services will free for customers.
