| Prod Model: |
AT050TN33 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Resolution: |
480*272 |
| Luminance: |
350CD/M2 |
| Contrast Ratio: |
500:1 |
| Operating Temperature: |
-20~70 |
| Storage Temperature: |
-30~80 |
| Type: |
TFT |
| Aspect Ratio: |
16:9 |
| Feature: |
LED Backlight Display |
| Application: |
Portable DV |
| Screen Size: |
5 Inch |
| Interface Type: |
Ttl |
Product Description
OEM 5 inch 480*272 TFT LCD Panel screen Innolux
5" TFT LCD with 40 pins, 5 inch TFT LCM display with/without TP
5 inch TFT LCD module for Portable GPS (AT050TN33 V. 1)
Brand: Innolux
Screen size: 5"
Resolution: 480*272
Luminance: 350CD/m2
Contrast Ratio: 500: 1
Aspect Ratio: 4: 3
Operating Temperature: -20~70
Storage Temperature: -30~80
Pixel Pitch: 0.1587x0.1587mm (WxH)
Weight: 108g(Typ. )
Surface: Antiglare
Active Area: 101.568x76.176mm (WxH)
Bezel Area: NA mm(WxH)
Outline Dimension: 117.65x88.43mm (WxH)
Outline Depth: 5.7mm (Typ. )
Touch Panel: Without TP
Response Time: 10/15(Typ. )(Tr/Td)
Viewing Angle: 70/70/50/70(Typ. )(CR>=10)(L/R/U/D)
Interface Type: FPC
Interface Pin Pitch: 0.5mm
Interface Pins: 40pins
Backlight: LED
