| Prod Model: |
PM550UD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
TFT |
| Application: |
Big-Screen Project |
| Aspect Ratio: |
16:9 |
| Feature: |
LCD Video Wall Display |
| Screen Size: |
55" |
| Interface Type: |
VGA, DVI, HDMI, Composit Video |
Product Description
Ultra-narrow bezel video wall with Samsung/LG Full HD panels (1920X1080). Tiled bezel width of LCDs is 5.5-6.7mm. VGA, DVI, HDMI inputs, 24/7/365 operation. Available in 46" 47" 55" sizes
Features and Benefits
1. Full HD LCD LED panel with 1920x1080 resolution, viewing angle: 178o (H/V)
450 nits/700nits birhgtness, high contrast ratio and colour saturation
2. 5.5mm almost seamless tiled bezel, excellent tiled visual performance
3. Metal case: anti-static,antimagnetic & anti-interference performance
4. Designed and engineered for 24/7 operation. Long lifetime: >50,000 hours.
5. Professional driving IC (adopting 3D comb filter and digital noise reduction technologies), ensuring high quality and stable colour performance.
6. Smart fan controlled by built in temperature sensor results in working temperature control.
7. Energy saving, very eco-friendly low power.
8. HDMI, DVI, VGA etc. multiple I/O ports allow for greater compatibility and flexibility.
9. Various installation methods: wall mount, floor stand, cabinet-mount etc.
10. Operation modes: RS232, Remote control, Key control
User applications: Conference rooms, office building, lobbies, Security Monitoring, Surveillance Retail Dynamic Signage, Restaurant Dynamic Signage, Retail Shopping Mall Advertising and information Displays, Public Installations, Exhibition, Live show, Museums, Transportation and Mass Info Display systems.
We are manufactuer and Tunkey Key solution integrator.
Product Description |
| Panel (LG Full HD IPSLED panel, Samsung DID LED panel) |
| Diagonal Size | 55" |
| Aspect Ratio | 16:9 |
| Pixel Pitch | 0.63(H)×0.63(V) |
| Response Time | 8ms |
| Resolution | 1920x1080 |
| Contrast Ratio | 3500:1 |
| Brightness (cd/m2) | 450cd/m2 (LED backlight) |
| Active display area | 1209.6(H)×680.4(V) |
| Display Color (Max) | 16.7M |
| Viewing Angle(U/D,L/R) | H:89o/89o V:89o/89o |
| Lifetime | More than 50,000 hours |
| Inputs |
| VGA | X1 |
| DVI | X1 |
| HDMI | X1 |
| YPbPr (BNC) | / |
| CVBS (BNC) | X2 |
| RJ45(for RS232 in) | X1 |
| RJ45(for debug) | X1 |
| Outputs |
| RJ45(for RS232 out) | X2 |
| CVBS | / |
| Product functions |
1. Video wall processor built in each screen
2. Scalable multi screen video wall (Maximum: 15x15 matrix)
3. Pixel shifting
4. Built-in temperature sensor & smart fan.
5. Support HD digital signals (DVI / HDMI)
6. Auto adjustment for color balance
7. On/Off Timer
8. License Agreement
9. Adaptively compensating the image for brightness loss to get contrast enhancement
10. Eco mode
11. Work status display |
|
|
|
|
|
|
|
|
|
|
