| Prod Model: |
SHM-BS/1380 |
| Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia |
| Cooling Method: |
Direct Cooling |
| Power Supply: |
Electric |
| Application: |
Greenhouse, Licestock, Poulty House and Workshop. |
| Certification: |
SGS |
| Power: |
>300W |
| Material: |
Stainless Steel |
| Installation: |
Wall Mounted |
| Type: |
Ventilation Fan |
Product Description
The Technical Data of 50inch Butterfly Cone Fan For Poultry Housing(SHM-BS/1380)
Ø Fan frame of exhaust fan: Hot galvanized sheet frame
Sheet thickness of exhaust fan is 1mm(left and right is 0.8mm)
Zink thickness is 275G/M
2
Ø Fan blades: Germany-imported mirror face stainless steel,
Fan blades No: 6
Fan Blade RPM: 460r/min
Fan blade Thickness: 1.2mm
Fan blade surfacegrfinishgrade.: BA
Blades all pass the balance test after assembled, which can assure steady running and even airflow during the operational life span of the life.
Ø Fan motor: The high efficient and energy-saving Simens motor (others motor accordingly ).
Fan motor protection grade: IP55
Fan motor insulation class: F
Fan belts: Japanese Mitsubishi brand
Ø Free maintenance: The whole use period is all free maintenance
Ø Performance: Cooling pad used together with better effect, it is used for longitudinal ventilation.
|
Model |
Diameter blade
/mm |
Diameter
No.s |
Frequency
/ HZ |
Air volume
/ m 3 /h |
Power/kw |
Noise(db) |
Voltage/v |
Size (mm) |
|
SHM-BT/1380 |
1270 |
3 |
50 |
52000 |
1.1 |
≤64 |
380 |
1380x1380x1280 |
|
SHM-BS/1380 |
1270 |
6 |
50 |
50280 |
1.1 |
≤64 |
380 |
1380x1380x1280 |
Qingdao Super Husbandry Machinery Co., Ltd is a famous enterprise engages in the study, designing and manufacturing of the husbandry ventilation equipments as well as the livestock and poultry ventilation. It is a hi-tech enterprise that enjoys the fast development speed, accompanied by the most effective technologies and top-ranking sales quantum.
Meanwhile, it has the ability of development, engineer designing, installing and servicing at the same time.
We have been supplying our products in China and overseas markets like the Asia, Middle East, Arab Countries, South America, etc. The excellent performance and services get a good reputation from the clients, we keep hard working to provide the better and better products and service for more and more customers
